OPTIONS
Codification table for voltages / Manual operator / Electrical connection
- Pilot operated valves 52, 67, 92, 93, 400, ISO1, ISO2, ISO3 Series
-DM- D XX X-X XX
1 2 3 4
VALVE CODE
®
OPTIONS AVAILABLE FOR
310
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
1. VOLTAGE
D-XX X-X XX
VOLTAGE
DA
24 VDC (5.4W)
DB
12 VDC (5.4W)
DC
12 VDC (7.5W)
DD
24 VDC (7.3W)
DE
12 VDC (12.7W)
DF
24 VDC (12.7W)
DK
110 VDC (4.7W)
DJ
28 VDC (5.2W)
DL
64 VDC (6.0W)
DM
36 VDC (5.3W)
DN
6 VDC (6.0W)
DR
90 VDC (6.6W)
DS
110 VDC (7.3W)
DT
75 VDC (5.6W)
DP
48 VDC (5.8W)
FA
12 VDC (1.8W)
FB
24 VDC (1.8W)
FE
12 VDC (2.4W)
FF
24 VDC (2.4W)
JA
120/60, 110/50 (2.9W)
JB
240/60, 220/50 (2.9W)
JC
24/60, 24/50 (3.7W)
JD
100/60, 100/50, 110/60 (3.9W)
JE
220/60 (3.4W)
JF
240/50 (2.8W)
JG
200/60, 200/50 (3.9W)
2. WIRE LENGTH
D-XX X-X XX
WIRE LENGTH
0
No wires
A
18"
B
24"
C
36"
D
48"
E
72"
F
96"
3. MANUAL OPERATOR
D-XX X-X XX
MANUAL OPERATOR
0
No operator
1
Non-locking recessed
2
Locking recessed
3
Non-locking extended
4
Locking extended
4. ELECTRICAL CONNECTION
D-XX X-X XX
ELECTRICAL CONNECTION
BA*
Flying leads (grommet)
BK*
BA with protection diode
BL*
BA with protection varistor
BM**
Flying leads (solenoid plug-in)
BN**
BM with protection diode
BP**
BM with protection varistor
BG**
BM with ground
BH**
BM with protection diode & ground
BJ**
BM with protection varistor & ground
CA*
1/2" NPS conduit with flying leads
CM*
1/2" NPS metal conduit with flying leads
CN*
1/2" NPS metal conduit with flying leads & ground
JB
Rectangular connector
JD
JB with light
JM
Rectangular connector (male only)
KA
Mini square connector
KB
KA with protection diode
KC
KA with protection varistor
KD
KA with light
KE
KA with light and protection diode
KF
KA with light and protection varistor
KG
KA with light & diode
KJ
Mini square connector (male only)
KK
KJ with protection diode (male only)
KL
KJ with protection varistor (male only)
TA
Dual tabs with receptacles
TB
TA with protection diode
TD
TA with light
TE
TA with light and protection diode
TJ
Dual tabs (male only)
TK
TJ with protection diode
TM
TJ with light
TN
TJ with light and protection diode
* From Lead wire length options choose A through F
** From Lead wire length options choose 0 through F
Note: When coil is above 30 volts, a ground wire is required. Applies to options
with flying leads.
