OPERATIONAL BENEFITS
Direct solenoid and solenoid pilot operated valves
HOW TO ORDER
81
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Series
46
Function Port size Flow (Max) Individual mounting Series
4/2 1/8” - # 10-32 0.3 C
v
Inline
1. Balanced poppet, immune to variations of
pressure.
2. Patented solenoid develops high shifting
forces.
3. Short stroke with high flow.
4. Higher forces result in lower wattages for
given flow.
5. Powerful return spring.
J
XXX
-
XXX
*
(-G) Add “G” for ground
SOLENOID OPERATOR
®
Voltage
Single & double solenoid
AA
120 VAC (5.4W)
DA
24 VDC (5.4W)
DB
12 VDC (5.4W)
Single solenoid only
DC
24 VDC (2.4W)
DD
12 VDC (2.4W)
Wire length
O
No leads
A
18”
B
24”
C
36”
Manual operator
1
Non-locking recessed
2
Locking recessed
Electrical connection
BA
Flying leads
GA
MAC JAC solenoid plug-in
GG
MAC JAC solenoid plug-in
with rectifier
JB
Rectangular connector
JD
Rectangular connector with
light
KA
Mini square
connector
KD
Mini square
connector
with
light
XX X X XX
* Other options available, see page 317.
** Use with rectangular and mini connectors
Note : - AC voltage requires connector with rectifier.
- With the MAC JAC, washdown capability is possible. Consult factory for washdown modification number.
Double solenoid requires minimum 5.4 watts.
Examples : 46A-DG1-Jxxx-xxx (Bottom O ring mount – all ports)
46A-CB1-Jxxx-xxx (4 port body with bottom ports – no side ports)
OPTIONS
46A-
AA
1-J
XXX
-
XXX
A Single operator - 4 port body with side ports
C Single operator - 4 port body with bottom ports (No side ports – M5 or #10-32 ONLY)
D Single operator - Bottom O ring mount – All ports (No side ports)
F Single operator - Bottom O ring mount – Cylinder ports only – Side inlet & exhaust
G Double operator - 4 Port body - With side ports
H Double operator - Bottom O ring mount - All ports (No side ports)
G Use with O ring mount (body option ‘D’ & ‘H’)
Port size
1/8” NPTF
# 10-32
Without flow controls
46A-AA1-J
XXX-XXX
46A-AB1-J
XXX-XXX
With flow controls
46A-AA2-J
XXX-XXX
46A-AB2-J
XXX-XXX
Without flow controls
46A-GA1-J
XXX-XXX
46A-GB1-J
XXX-XXX
With flow controls
46A-GA2-J
XXX-XXX
46A-GB2-J
XXX-XXX
AB
AB
EXH IN
AB
AB
EXH IN
AB
AB
EXH IN
AB
AB
EXH IN
Single Operator
Double Operator
**
16.3
8.5
IN
EX
32.5
70.9
3.2 DIA.
22.5
26.5
8.0
11.4
15.7
3.8
25.8
3.0
7.5
11.8
15.2
43.3
1/8" PORTS
25.8
3.8
10.9
109.4
43.3
3.0
15.7
8.0
EX
IN
8.0
15.2
11.0
32.7
7.5
26.5
38.0
18.8
Ø 3.4
TYP. (2)
CONTROLS
w/FLOW
22.5
CONTROLS
w/o FLOW
Double solenoidSingle solenoid
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
82
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series
46
Fluid :
Pressure range :
Lubrication :
Filtration :
Temperature range :
Orifice :
Flow :
Coil :
Voltage range :
Protection :
Power :
Compressed air, vacuum, inert gases
Vacuum to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F and 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
3,3 mm
1.8W : (0.20 C
v
) – 2.4W : (0.20 C
v
) – 5.4W : (0.30 C
v
)
Class A wire (#22 AWG x 18), continuous duty
-15% to +10% of nominal voltage
Consult factory
5.4W – 2.4W – 1.8W
• BSPP threadsOptions :
OPERATIONAL BENEFITS
Direct solenoid and solenoid pilot operated valves
HOW TO ORDER
83
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Series
46
Function Port size Flow (Max) Manifold Mounting Series
4/2 1/8” - # 10-32 0.3 C
v
Stacking
1. Balanced poppet, immune to variations of
pressure.
2. Patented solenoid develops high shifting
forces.
3. Short stroke with high flow.
4. Higher forces result in lower wattages for
given flow.
5. Powerful return spring.
Port size
1/8” NPTF
# 10-32
Without flow controls
46A-SA1-J
XXX-XXX
46A-SB1-J
XXX-XXX
With flow controls
46A-SA2-J
XXX-XXX
46A-SB2-J
XXX-XXX
AB
AB
EXH IN
J
XXX
-
XXX
*
(-G) Add “G” for ground
SOLENOID OPERATOR
®
Voltage
AA
120 VAC (5.4W)
DA
24 VDC (5.4W)
DB
12 VDC (5.4W)
DC
24 VDC (2.4W)
DD
12 VDC (2.4W)
Wire length
A
18”
B
24”
C
36”
Manual operator
1
Non-locking recessed
2
Locking recessed
Electrical connection
BA
Flying leads
GA
MAC JAC solenoid plug-in
GB
MAC JAC solenoid plug-in
with diode
GG
MAC JAC solenoid plug-in
with rectifier
XX X X XX
* Other options available, see page 317.
Note : - AC voltage requires connector with rectifier.
- With the MAC JAC, washdown capability is possible. Consult factory for washdown modification number.
End plate kit required (port size 1/4") : M-46001-01.
