- TYP. TYP. TYP. TYP. TYP. TYP. 19.8 10.5 32.6 10.1 15.0 27.4 12.7 7.0 Ø 5.3 21.1 152.0 4.9 Ø 5.3 33.6 152.0 5.0 CONTROLS WITHOUT FLOW CONTROLS WITH FLOW PORTS 1/8" CYLINDER EXHAUST COMMONS 1/4" INLET AND 44.1 …

100%1 / 280
OPERATIONAL BENEFITS
Direct solenoid and solenoid pilot operated valves
HOW TO ORDER
83
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Series
46
Function Port size Flow (Max) Manifold Mounting Series
4/2 1/8” - # 10-32 0.3 C
v
Stacking
1. Balanced poppet, immune to variations of
pressure.
2. Patented solenoid develops high shifting
forces.
3. Short stroke with high flow.
4. Higher forces result in lower wattages for
given flow.
5. Powerful return spring.
Port size
1/8” NPTF
# 10-32
Without flow controls
46A-SA1-J
XXX-XXX
46A-SB1-J
XXX-XXX
With flow controls
46A-SA2-J
XXX-XXX
46A-SB2-J
XXX-XXX
AB
AB
EXH IN
J
XXX
-
XXX
*
(-G) Add “G” for ground
SOLENOID OPERATOR
®
Voltage
AA
120 VAC (5.4W)
DA
24 VDC (5.4W)
DB
12 VDC (5.4W)
DC
24 VDC (2.4W)
DD
12 VDC (2.4W)
Wire length
A
18”
B
24”
C
36”
Manual operator
1
Non-locking recessed
2
Locking recessed
Electrical connection
BA
Flying leads
GA
MAC JAC solenoid plug-in
GB
MAC JAC solenoid plug-in
with diode
GG
MAC JAC solenoid plug-in
with rectifier
XX X X XX
* Other options available, see page 317.
Note : - AC voltage requires connector with rectifier.
- With the MAC JAC, washdown capability is possible. Consult factory for washdown modification number.
End plate kit required (port size 1/4") : M-46001-01.
-
TYP.
TYP.
TYP.
TYP.
TYP.
TYP.
19.8
10.5
32.6
10.1
15.0
27.4
12.7
7.0
Ø 5.3
21.1
152.04.9
Ø 5.3
33.6
152.05.0
CONTROLS
WITHOUT FLOW
CONTROLS
WITH FLOW
PORTS
1/8" CYLINDER
EXHAUST COMMONS
1/4" INLET AND
44.1
16.5
162.0
71.5
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
84
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series
46
Fluid :
Pressure range :
Lubrication :
Filtration :
Temperature range :
Flow :
Coil :
Voltage range :
Protection :
Power :
Response times :
(with 5.4 W coil)
Compressed air, vacuum, inert gases
Vacuum to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F and 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
1.8W : (0.20 C
v
) – 2.4W : (0.20 C
v
) – 5.4W : (0.30 C
v
)
Class A wire (#22 AWG x 18), continuous duty
-15% to +10% of nominal voltage
Consult factory
5.4W – 2.4W – 1.8W
Energize : 7.20 ms
De-energize : 4.20ms
• BSPP threads
• Inlet isolator : 28494 • Exhaust isolator : 28493 • Tie rod (x2) : 79411
Options :
Spare parts :
OPERATIONAL BENEFITS
Direct solenoid and solenoid pilot operated valves
HOW TO ORDER
85
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
46
Series
46
Function Port size Flow (Max) Manifold mounting Series
4/2 1/8" - 5/32 O.D. Pressed-in 0.3 C
v
tube receptacles
Manifold base
“plug-in”
1. Balanced poppet, immune to variations of
pressure.
2. Patented solenoid develops high shifting
forces.
3. Short stroke with high flow.
4. Higher forces result in lower wattages for
given flow.
5. Powerful return spring.
Port size
Valve less base
1/8” NPTF
5/32 O.D. Pressed-in tube receptacles
Single solenoid
46A-L00-00-J
XX
P
-XXX
46A-LSA-AC-J
XX
P
-XXX
46A-LSF-AC-J
XX
P
-XXX
Double solenoid
46A-N00-00-J
XX
P
-XXX
46A-NSA-BL-J
XX
P
-XXX
46A-NSF-BL-J
XX
P
-XXX
AB
AB
EXH IN
* Other options available, see page 317.
Note : AC voltage requires connector with rectifier. Double solenoid requires minimum 5.4 watts.
Example : base only : 46A-0SA-AC.
End plate kit required (port size 1/4") : M-46003-01.
OPTIONS
46A-
L
SB-A
C
-J
XX
P-
XXX
0 Base only - no valve
L Single solenoid - Base mount body
M Single solenoid - Base mount body with gage port
N Double solenoid - Base mount body
P Double solenoid - Base mount body with gage port
C Single solenoid - Side cylinder ports
L Single & double solenoid - Bottom cylinder ports
Voltage
Single & double solenoid
AA
120 VAC (5,4W)
AC
24 VAC (5,4W)
DA
24 VDC (5,4W)
DB
12 VDC (5,4W)
Single solenoid only
DC
24 VDC (2,4W)
DD
12 VDC (2,4W)
Manual operator
1
Non-locking
2
Locking
Electrical connection
FA
Base plug-in
FB
Base plug-in with diode
FG
Base plug-in with rectifier
J
XX
P-
XXX
*
(-G) Add “G” for ground
SOLENOID OPERATOR
®
XX X XX
AB
AB
EXH IN
