310
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
1. VOLTAGE
D-XX X-X XX
VOLTAGE
DA
24 VDC (5.4W)
DB
12 VDC (5.4W)
DC
12 VDC (7.5W)
DD
24 VDC (7.3W)
DE
12 VDC (12.7W)
DF
24 VDC (12.7W)
DK
110 VDC (4.7W)
DJ
28 VDC (5.2W)
DL
64 VDC (6.0W)
DM
36 VDC (5.3W)
DN
6 VDC (6.0W)
DR
90 VDC (6.6W)
DS
110 VDC (7.3W)
DT
75 VDC (5.6W)
DP
48 VDC (5.8W)
FA
12 VDC (1.8W)
FB
24 VDC (1.8W)
FE
12 VDC (2.4W)
FF
24 VDC (2.4W)
JA
120/60, 110/50 (2.9W)
JB
240/60, 220/50 (2.9W)
JC
24/60, 24/50 (3.7W)
JD
100/60, 100/50, 110/60 (3.9W)
JE
220/60 (3.4W)
JF
240/50 (2.8W)
JG
200/60, 200/50 (3.9W)
2. WIRE LENGTH
D-XX X-X XX
WIRE LENGTH
0
No wires
A
18"
B
24"
C
36"
D
48"
E
72"
F
96"
3. MANUAL OPERATOR
D-XX X-X XX
MANUAL OPERATOR
0
No operator
1
Non-locking recessed
2
Locking recessed
3
Non-locking extended
4
Locking extended
4. ELECTRICAL CONNECTION
D-XX X-X XX
ELECTRICAL CONNECTION
BA*
Flying leads (grommet)
BK*
BA with protection diode
BL*
BA with protection varistor
BM**
Flying leads (solenoid plug-in)
BN**
BM with protection diode
BP**
BM with protection varistor
BG**
BM with ground
BH**
BM with protection diode & ground
BJ**
BM with protection varistor & ground
CA*
1/2" NPS conduit with flying leads
CM*
1/2" NPS metal conduit with flying leads
CN*
1/2" NPS metal conduit with flying leads & ground
JB
Rectangular connector
JD
JB with light
JM
Rectangular connector (male only)
KA
Mini square connector
KB
KA with protection diode
KC
KA with protection varistor
KD
KA with light
KE
KA with light and protection diode
KF
KA with light and protection varistor
KG
KA with light & diode
KJ
Mini square connector (male only)
KK
KJ with protection diode (male only)
KL
KJ with protection varistor (male only)
TA
Dual tabs with receptacles
TB
TA with protection diode
TD
TA with light
TE
TA with light and protection diode
TJ
Dual tabs (male only)
TK
TJ with protection diode
TM
TJ with light
TN
TJ with light and protection diode
* From Lead wire length options choose A through F
** From Lead wire length options choose 0 through F
Note: When coil is above 30 volts, a ground wire is required. Applies to options
with flying leads.
311
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
Codification table for voltages / Manual operator / Electrical connection
- Solenoid valves 32, 34, 38, 42, 44 & 48 Series
G XX X-X XX
1 2 3 4
VALVE CODE
®
OPTIONS AVAILABLE FOR
312
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
1. VOLTAGE
G-XX X-X XX
VOLTAGE
AA
120 VAC (2.5W)
Requires electrical connector with rectifier
AC
24 VAC (4.0W)
Requires electrical connector with rectifier
DA
24 VDC (1.0W)
DC
24 VDC (1.8W)
DD
24 VDC (2.5W)
DE
24 VDC (3.0W)
DF
24 VDC (4.0W)
DG
12 VDC (1.0W)
DJ
12 VDC (1.8W)
DK
12 VDC (2.5W)
DM
12 VDC (3.0W)
DN
12 VDC (4.0W)
DR
6 VDC (1.8W)
DS
6 VDC (3.0W)
EB
48 VDC (1.8W)
EC
48 VDC (3.0W)
ED
120 VDC (2.5W)
GD
12 VDC (0.5W) 34 series only
GE
24 VDC (0.5W) 34 series only
2. WIRE LENGTH
G-XX X-X XX
WIRE LENGTH
0
No lead wires (used only with "KJ" & "KM" connectors)
A
18" coil leads
B
24" coil leads
C
36" coil leads
D
48" coil leads
E
72" coil leads
F
96" coil leads
G
120" coil leads
H
144" coil leads
1
18" base leads
2
24" base leads
3
36" base leads
4
48" base leads
5
72" base leads
6
96" base leads
7
120" base leads
3. MANUAL OPERATOR
G-XX X-X XX
MANUAL OPERATOR
1
Non-locking recessed
2
Locking recessed
3
Non-locking extended
4
Locking extended
4. ELECTRICAL CONNECTION
G-XX X-X XX
ELECTRICAL CONNECTION
BA
Flying leads
BB
BA with ground wire
BC
BA with light
BD
BA with light and ground wire
BE
BA with suppression diode
BF
BA with suppression diode and ground wire
BG
BA with suppression diode and light
BH
BA with suppression diode, light and ground wire
BN
BA with suppression diode and blocking diode
BP
BA with suppression diode, blocking diode and ground wire
BR
BA with suppresion diode, blocking diode and light
BS
BA with suppression diode, blocking diode, light and ground
wire
GA
MAC JAC Solenoid plug-in
GB
MAC JAC Solenoid plug-in w/Diode
GC
MAC JAC Solenoid plug-in w/MOV
GD
MAC JAC Solenoid plug-in w/LED
GE
MAC JAC Solenoid plug-in w/Diode & LED
GF
MAC JAC Solenoid plug-in w/MOV & LED
GG
MAC JAC Solenoid plug-in w/Rectifier
GH
MAC JAC Solenoid plug-in w/Rectifier & LED
KA
Solenoid plug-in wire assembly
KB
KA with ground
KC
KA with rectifier and light
KD
KA with rectifier, light and ground
KE
KA with suppression diode
KF
KA with suppression diode and ground
KJ
Solenoid plug-in housing without wire assembly
KM
Solenoid plug-in housing with ground pin without wire
assembly
KN
KA with suppression diode and blocking diode
KP
KA with suppression diode, blocking diode and ground
KT
KA with light
KU
KA with light and ground
KV
KA with suppression diode and light
KW
KA with suppression diode, light and ground
KX
KA with suppression diode, blocking diode and light
KY
KA with suppression diode, blocking diode, light & ground
ELECTRICAL CONNECTION FOR PLUG-IN VALVES
G-XX X-X XX
PLUG-IN OPTIONS
SB
Base plug-in with ground
SC
Base plug-in with suppression and blocking diode
SD
Base plug-in with suppression and blocking diode and ground
SE
Base plug-in with MOV
SF
Base plug-in with MOV and ground
SG
Base plug-in with rectifier
SH
Base plug-in with rectifier and ground
SK
Base plug-in with light and ground
SL
Base plug-in with suppression and blocking diode and light
SM
Base plug-in with suppression and blocking diode with light
and ground
SN
Base plug-in with MOV and light
SP
Base plug-in with MOV and light with ground
SR
Base plug-in with rectifier and light
