OPERATIONAL BENEFITS Direct solenoid and solenoid pilot operated valves HOW TO ORDER 121 Consult “Precautions” page 327 before use, installation or service of MAC Valves.. 36 32 37 38 33 34 52 67 46 44 47 42 400 48 92 93…
119
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Individual mounting Series
Direct solenoid and solenoid pilot operated valves
SERIES FEATURES
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Series
48P
• High force MACSOLENOID
®
.
• Integral 4-way pilot with poppet inside the spool.
• Large flow in compact package.
• Single or dual pressure.
• Rectified AC voltage.
5
42
13
Manual operator
4-way pilot with
“poppet in spool” design
Solenoid
Bonded spool
Inline
OPERATIONAL BENEFITS
Direct solenoid and solenoid pilot operated valves
HOW TO ORDER
121
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Series
48P
Function Port size Flow (Max) Individual mounting Series
5/2 1/8” 1.0 C
v
Inline
1. 4-way valve with 4-way pilot.
2. Poppet in spool design
3. 16 mm valve (stacks on 16.5 mm centers).
4. High flow (up to 1.0 Cv).
5. Fast repeatable response times.
6. Maximum shifting forces in both directions.
7. Long life.
8. Compact design.
5/2 Single operator
Single pressure
48PB-AAA-A00-G
XXX
-
XXX
-
-
5/2 Single operator
Dual pressure
-
48PB-CAB-A00-G
XXX
-
XXX
48PB-CAC-A00-G
XXX
-
XXX
Port size
1/8”
Pilot
Internal
Internal from port 3
Internal from port 5
24
1214
3
1
5
24
12 14
315
G
XXX
-
XXX
*
STANDARD SOLENOID OPERATOR
®
Voltage
AA
120 VAC (2.5W)
DC
24 VDC (1.8W)
DD
24 VDC (2.5W)
DF
24 VDC (4.0W)
Wire length
A
18”
B
24”
C
36”
Manual operator
1
Non-locking
2
Locking
Electrical connection
BA
Flying leads
BT
Flying leads with light
GA
MAC JAC solenoid
plug-in
KA
Plug-in wire assy.
KT
Plug-in wire assy. with light
KD
Plug-in wire assy. with
rectifier & light & ground
XX X X XX
* Other options available, see page 311.
Note : AC voltage requires connector with rectifier.
48PB-X X X-X00-G
XX
-
XXX
OPTIONS
A Pilot exhaust muffled
C Pilot exhaust piped M5
D Pilot exhaust out main exhaust
2 4
VAC TO 150 PSI
MODIF.
AUCKLAND, N.Z.
LIEGE, BELGIUM
WIXOM, MI. USA
MODEL
35 1
8.0
16.0
16.0
33.4
113.0
1/8"- BSPP (5 PLACES)
4.7
35.5
56.3
13.2
82.8
Ø 4.2
8.0
15.5
15.5
25.9
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
122
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series
48P
Fluid :
Pressure range :
Lubrication :
Filtration :
Temperature range :
Flow :
Coil :
Voltage range :
Power :
Compressed air, vacuum, inert gases
25 to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F and 210°F)
40 µ
0°F to 120°F (18°C to +50°C)
Cv 1,0
Class A wire continuous duty, #22 AWG x 18 leads
-15% to +10% of nominal voltage
1.0 to 4.0 W
• BSPP threadsOptions :
