Function Port size Flow (Max) Individual mounting Series OPERATIONAL BENEFITS Direct solenoid and solenoid pilot operated valves HOW TO ORDER 47 Consult “Precautions” page 327 before use, installation or service of MAC V…
45
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Individual mounting Series
Direct solenoid and solenoid pilot operated valves
SERIES FEATURES
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Inline
Sub-base
non plug-in
Series
37
• Balanced poppet equals consistent high shifting forces.
• Valve shifting forces are consistent and independent of pressure fluctuations.
• High solenoid and return spring forces ensure high speed and precise repeatability.
• Built-in wear compensation - valve stroke is shorter than solenoid stroke.
• Constant high flow maintained throughout the pressure range.
• Exhaust contaminants are isolated from the solenoid.
• Full flow exhaust.
• Universal porting - 6 functions in one valve.
1
3
2
Push pin
Manual operator
Armature
Coil
“D” seal
Poppet
Valve return spring
Pole piece
Function Port size Flow (Max) Individual mounting Series
OPERATIONAL BENEFITS
Direct solenoid and solenoid pilot operated valves
HOW TO ORDER
47
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Series
37
3/2 NO-NC 1/8” - 1/4” 0.5 C
v
Inline
1. Balanced poppet equals consistent high shifting
forces.
2. Valve shifting forces are consistent and independent
of pressure fluctuations.
3. High solenoid and return spring forces ensure high
speed and precise repeatability.
4. Built-in wear compensation – valve stroke is shorter
than solenoid stroke.
5. Constant high flow maintained throughout the
pressure range.
6. Exhaust contaminants are isolated from the solenoid.
7. Full flow exhaust.
8. Universal porting – 6 functions in one valve.
Port size
1/8” NPTF
1/4” NPTF
Universal valve
37A-AA0-H
XXX-XXX
37A-AB0-H
XXX-XXX
NC only valve
37A-BA0-H
XXX-XXX
37A-BB0-H
XXX-XXX
2
13
2
13
H
XXX
-
XXX
*
SOLENOID OPERATOR
®
Voltage
AA
120 VAC (6.7W)
DA
24 VDC (5.2W)
DB
24 VDC (2.4W)
DC
24 VDC (1.8W)
Wire length
A
18”
B
24”
Manual operator
1
Non-locking recessed
2
Locking recessed
Electrical connection**
MA
Plug-in wire assembly
MC
Plug-in wire assembly
with
light
BA
Flying leads
BC
Flying leads with light
MT
Plug-in wire assembly with
rectifier & light
XX X X XX
Note : AC voltage requires connector with rectifier.
* Other options available, see page 315.
67.4
TYP. (2)
MTG. HOLES
4.25 DIA.
36.0
97.5
12
10
1
3
2
A
B
23.0
9.0
18.0
9.0
6.0
TYP.(2)
7.2
32.7
TYP.(2)
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
48
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Dim
1/8”
1/4”
A
13.3
14.7
B
32.45
33.7
Series
37
Fluid :
Pressure range :
Lubrication :
Filtration :
Temperature range :
Flow :
Coil :
Voltage range :
Power :
Response times :
(with 5.2 W coil)
Compressed air, vacuum, inert gases
Vacuum to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F and 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
5.2 W : (0.5 C
v
) – 2.4 W : (0.35 C
v
)
Class A wire (#22 AWG x 18), continuous duty
-15% to +10% of nominal voltage
5.2 W – 2.4 W
Energize : 16.9 ms
De-energize : 6.7 ms
• BSPP portsOptions :
Shown with Mini Square Connector (“K” Type)
