1/8"-27 N.P .T .F . TYP . (2) 1/8"-27 N.P .T .F TYP . (2) 1/4"-18 N.P .T .F . TYP . (3) 1/4"-18 N.P .T .F TYP . (3) RIGHT SIDE LEFT SIDE 1/8"-27 N.P .T .F . 50.00 50.65 42.00 1/8"-27 N.P .T …
Bases according to ISO 154079/1
HOW TO ORDER
229
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
ISO 01
ISO 02
ISO 1
ISO 2
ISO 3
Series
Series
ISO 02
Port size
1/8” NPTF
Pilot air
Internal
Side ports
MB-A02A-111
Bottom 2 & 4 ports
With all side ports
MB-A02A-112
INDIVIDUAL BASE
Port size
1/8” NPTF
Pilot air
Internal
Side ports
MM-A02A-111
Bottom 2 & 4 ports
With side 1, 3 & 5 ports
MM-A02A-112
MANIFOLD BASE
Notes:
- For manifold bases external pilot is common
- A base is ordered as internal pilot and can be changed into external pilot by removing pipe plugs from the external pilot ports (individual base).
- Manifold base: same base for internal and external pilot, different end plate kits.
End plate kit: Internal pilot M-00018-01-01
External pilot M-00018-02-01
Inlet/exhaust isolator: 28499
Non plug-in individual / manifold base
1/8"-27 N.P.T.F. TYP. (2)
1/8"-27 N.P.T.F TYP. (2)
1/4"-18 N.P.T.F. TYP. (3)
1/4"-18 N.P.T.F TYP. (3)
RIGHT SIDE
LEFT SIDE
1/8"-27 N.P.T.F.
50.00
50.65
42.00
1/8"-27 N.P.T.F.
27.60
7.80
7.50
12.80
11.50
42.00
9.50
19.00
17.70
35.00
11.75
33.75
55.65
18.30
11.75
55.65
33.75
18.30
50.65
17.70
42.00
35.00
22.70
17.50
TYP.(2)
TYP.(2)
P
P
TYP.(2)
TYP.(2)
TYP.(2)
DIMENSIONS
Dimensions shown are metric (mm)
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
230
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series
ISO 02
4.561.35
3.50
26.50
4.25 DIA. DRILL - THRU
15.00
27.00
43.00
42.00
28.00
70.35
17.75
33.50
15.00
23.00
19.00
51.00
8.00
20.45
49.55
35.00
17.75
15.00
1/8"-27 N.P.T.F. TYP. (7) PLACES
TYP. (2)
TYP. (2)
TYP. (3)
Individual
Manifold
Bases according to ISO 5599/1
HOW TO ORDER
231
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
ISO 01
ISO 02
ISO 1
ISO 2
ISO 3
Series
Series
ISO 1
Series
Port size
1/4” NPTF
3/8” NPTF
Side ports
MB-A1C-221
MB-A1C-231
Side & bottom ports
MB-A1C-223
MB-A1C-233
Bottom cylinder
ports 2 and 4.
MB-A1C-222
MB-A1C-232
Bottom inlet port 1
MB-A1C-224
MB-A1C-234
INDIVIDUAL BASE
Port size
1/4” NPTF
3/8” NPTF
Side ports
MM-A1C-221
MM-A1C-231
Side & bottom ports
MM-A1C-223
MM-A1C-233
Bottom cylinder
ports 2 and 4.
MM-A1C-222
MM-A1C-232
Bottom inlet port 1
MM-A1C-224
MM-A1C-234
MANIFOLD BASE
Manifold fastening kit : N-63002-01.
Valve blanking plate: MA1003.
Inlet/exhaust isolator plug: 32835.
Non plug-in base / manifold
