321 Consult “Precautions” page 327 before use, installation or service of MAC Valves.. OPTIONS Codification table for voltages / Manual operators / Electrical connections - Solenoid valves 33 Series OPTIONS AVAILABLE FOR…
318
Consult “Precautions” page 327 before use, installation or service of MAC V
alves..
O P TIONS
1. VOLTAGE
J-XX X-X XX
VOLTAGE
AA
120VAC (5.4W)
AC
24VAC (5.4W)
DE
24VDC (1.8W)
DF
12VDC (1.8W)
DJ
24VDC (1.3W)
DL
12VDC (1.3W)
DR
12VDC (1.0W)*
DU
24VDC (1.0W)*
* Not available on 36 series universal valve
2. WIRE LENGTH
J-XX X-X XX
WIRE LENGTH
A
18" coil leads
B
24" coil leads
C
36" coil leads
D
48" coil leads
E
72" coil leads
F
96" coil leads
P
Base plug-in
O
No leads (use with J, K & L type connectors)
3. MANUAL OPERATOR
J-XX X-X XX
MANUAL OPERATOR
0
No operator
1
Non-locking recessed
2
Locking recessed
3
Non-locking extended
4
Locking extended
4. ELECTRICAL CONNECTION
CONNECTORS FOR NON PLUG-IN VALVES
J-XX X-X XX
ELECTRICAL CONNECTION
BA
Flying leads
GA
MAC JAC solenoid plug-in
GB
MAC JAC solenoid plug-in with diode
GC
MAC JAC solenoid plug-in with MOV
GD
MAC JAC solenoid plug-in with light
GE
MAC JAC solenoid plug-in with diode and light
GF
MAC JAC solenoid plug-in with MOV and light
GG
MAC JAC solenoid plug-in with rectier
GH
MAC JAC solenoid plug-in with rectier and light
GJ
MAC JAC solenoid plug-in – Male only
GK
MAC JAC solenoid plug-in with diode – Male only
GL
MAC JAC solenoid plug-in with MOV – Male only
GM
MAC JAC solenoid plug-in with light – Male only
GN
MAC JAC solenoid plug-in with diode and light – Male only
GP
MAC JAC solenoid plug-in with MOV and light – Male only
GR
MAC JAC solenoid plug-in with rectier – Male only
GS
MAC JAC solenoid plug-in with rectier and light – Male only
*JA
Square Connector
*JC
Square Connector with light
*JE
Square Connector with diode
*JF
Square Connector
with MOV
*JG
Square Connector
with
diode/light
*JH
Square Connector
with MOV
/light
*JK
Square Connector
with Rectier
J-XX X-X XX
*JL
Square Connector
with Rectier with
light
*JJ
Square Connector
Male only (Plain)
*JB
Rectangular Connector
*JD
Rectangular Connector with light
*JN
Rectangular Connector with diode
*JP
Rectangular Connector
with MOV
*JR
Rectangular Connector
with
diode/light
*JS
Rectangular Connector
with MOV
/light
*JT
Rectangular Connector
with Rectier
*JU
Rectangular Connector
with Rectier with
light
*JM
Rectangular Connector
Male only (Plain)
* Not available on manifold or stacking valves
CONNECTORS FOR NON PLUG-IN VALVES
J-XX X-X XX
MINI SQUARE PLUG-IN CONNECTORS
9.4 MM SPACING BETWEEN PINS
KA
Mini plug-in
KB
Mini plug-in with diode
KC
Mini plug-in with MOV
KD
Mini plug-in with light
KE
Mini plug-in with diode and light
KF
Mini plug-in with MOV and light
KG
Mini plug-in with rectier
KH
Mini plug-in with rectier and light
KJ
Mini plug-in – Male only
KK
Mini plug-in with diode - Male only
KL
Mini plug-in with MOV - Male only
KM
Mini plug-in with light - Male only
KN
Mini plug-in with diode and light – Male only
KP
Mini plug-in with MOV and light – Male only
KR
Mini plug-in with rectier – Male only
KS
Mini plug-in with rectier and light – Male only
CONNECTORS FOR NON PLUG-IN VALVES
J-XX X-X XX
MINI SQUARE PLUG-IN CONNECTORS
8.0 MM SPACING BETWEEN PINS
ISO SPECIFICATION 15217
LA
Mini plug-in
LB
Mini plug-in with diode
LC
Mini plug-in with MOV
LD
Mini plug-in with light
LE
Mini plug-in with diode and light
LF
Mini plug-in with MOV and light
LG
Mini plug-in with rectier
LH
Mini plug-in with rectier and light
LJ
Mini plug-in – Male only
LK
Mini plug-in with diode - Male only
LL
Mini plug-in with MOV - Male only
LM
Mini plug-in with light - Male only
LN
Mini plug-in with diode and light – Male only
LP
Mini plug-in with MOV and light – Male only
LR
Mini plug-in with rectier – Male only
LS
Mini plug-in with rectier and light – Male only
J-XX X-X XX
CONNECTORS FOR PLUG-IN VALVES
FA
Base plug-in
FB
Base plug-in with diode
FC
Base plug-in with MOV
FD
Base plug-in with light
FE
Base plug-in with diode and light
FF
Base plug-in with MOV and light
FG
Base plug-in with rectier
FH
Base plug-in with rectier and light
321
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
Codification table for voltages / Manual operators / Electrical connections
- Solenoid valves 33 Series
OPTIONS AVAILABLE FOR
R XX X-X XX
1 2 3 4
VALVE CODE
®
322
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
1. VOLTAGE
R-XX X-X XX
VOLTAGE
DA
24 VDC (0.5W)
DB
24 VDC (1.0W)
DC
24 VDC (1.8W)
DD
24 VDC (2.5W)
DE
24 VDC (3.0W)
DF
24 VDC (4.0W)
DG
12 VDC (0.5W)
DH
12 VDC (1.0W)
DJ
12 VDC (1.8W)
DK
12 VDC (2.5W)
DL
12 VDC (3.0W)
DM
12 VDC (4.0W)
EA*
24 VDC (60W)
EB*
24 VDC (90W)
EC*
24 VDC (230W)
2. WIRE LENGTH (all series)
R-XX X-X XX
WIRE LENGTH
0**
No lead wire
A
18"
B
24"
C
36"
D
48"
E
72"
F
96"
G
120"
H
144"
3. MANUAL OPERATOR
R-XX X-X XX
MANUAL OPERATOR
0
No operator
1
Non-locking recessed
3
Non-locking extended
4. ELECTRICAL CONNECTOR
R-XX X-X XX
NON PLUG-IN
BA
Flying leads
BB
Flying leads with LED
BC
Flying leads with MOV
BD
Flying leads with LED and MOV
RA
Mini JAC solenoid plug-in
RB
Mini JAC solenoid plug-in with LED
RC
Mini JAC solenoid plug-in with MOV
RD
Mini JAC solenoid plug-in with LED and MOV
TA
JST solenoid plug-in
TB
JST solenoid plug-in with LED
TC
JST solenoid plug-in with MOV
TD
JST solenoid plug-in with LED and MOV
*MOD numbers required for these voltages (consult factory) ** Not available for flying leads connector
