Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
Codification table for voltages / Manual operators / Electrical connections
- Solenoid valves 52 & 400 Series
OPTIONS AVAILABLE FOR
-GM- G XX X-X XX
1 2 3 4
VALVE CODE
®
314
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
1. VOLTAGE
G-XX X-X XX
VOLTAGE
DC
24 VDC (1.8 W)
DD
24 VDC (2.5 W)
DE
24 VDC (3.0 W)
DF
24 VDC (4.0 W)
DJ
12 VDC (1.8 W)
DK
12 VDC (2.5 W)
DM
12 VDC (3.0 W)
DN
12 VDC (4.0 W)
2. WIRE LENGTH
G-XX X-X XX
WIRE LENGTH
0
No lead wire (use only with "KJ" & "KM" elecrical
connectors)
A
18"
B
24"
C
36"
D
48"
E
72"
F
96"
G
120"
H
144"
3. MANUAL OPERATOR
G-XX X-X XX
MANUAL OPERATOR
1
Non-locking recessed
2
Locking recessed
3
Non-locking extended
4
Locking extended
4. ELECTRICAL CONNECTION
G-XX X-X XX
ELECTRICAL CONNECTION
BA
Flying leads
BB
BA with ground wire
BC
BA with light parallel to leads
BD
BA with light parallel to leads & ground wire
BE
BA with suppression diode
BF
BA with suppression diode & ground wire
BG
BA with suppression diode plus light parallel to leads
BH
BA with suppression diode plus light parallel to leads &
ground wire
*BN
BA with suppression diode plus blocking diode
*BP
BA with suppression diode plus blocking diode & ground
wire
*BR
BA with suppression diode plus blocking diode & light
parallel to leads
*BS
BA with suppression diode plus blocking diode & light
parallel to leads & ground wire
BT
BA with light on top
BU
BA with light on top & ground wire
BV
BA with suppression diode plus light on top
BW
BA with suppression diode plus light on top & ground wire
*BX
BA with suppression diode plus blocking diode & light on top
*BY
BA with suppression diode plus blocking diode & light on
top & ground wire
G-XX X-X XX
SOLENOID PLUG-IN CONNECTOR WITH LEADS
GA
MAC JAC Solenoid plug-in
GB
MAC JAC Solenoid plug-in w/Diode
GC
MAC JAC Solenoid plug-in w/MOV
GD
MAC JAC Solenoid plug-in w/LED
GE
MAC JAC Solenoid plug-in w/Diode & LED
GF
MAC JAC Solenoid plug-in w/MOV & LED
GG
MAC JAC Solenoid plug-in w/Rectifier
GH
MAC JAC Solenoid plug-in w/Rectifier & LED
KA
Plug-in wire assembly
KB
KA with ground wire
KE
KA with suppression diode
KF
KA with suppression diode & ground wire
KJ
Plug-in housing without wire assembly
('KA' without wire assembly)
KM
Plug-in housing without wire assembly
('KB' without wire assembly)
*KN
KA with suppression diode plus blocking diode
*KP
KA with suppression diode plus blocking diode & ground wire
KT
KA with light on top
KU
KA with light on top & ground wire
KV
KA with suppression diode plus light on top
KW
KA with suppression diode plus light & ground wire
*KX
KA with suppression diode plus blocking diode & light on top
*KY
KA with suppression diode plus blocking diode & light on
top & ground wire
Note: Blocking diode is located in the lead wire
