HOW TO ORDER 251 Consult “Precautions” page 327 before use, installation or service of MAC Valves.. Pressure regulators OPERATIONAL BENEFITS Series Series PR46A Sandwich-pressure regulator 1. Easy mounting: saves on inst…
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
250
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series PR42B
Fluid :
Pressure range :
Regulating range :
Lubrication :
Filtration :
Temperature range :
Flow :
Compressed air, inert gases
0 to 120 PSI
0 to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F to 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
0.25 C
v
166.6
180.6
-+
L
O
C
K
-+
L
O
C
K
-+
L
O
C
K
-+
L
O
C
K
2
4
2
4
4
2
4
2
X
5
3
1
101.7
3
1
5
113.2
• Pressure regulator (less sandwich block) : PR42B-C0xx • Gage port plug: N-PE003
• #10 -32 to 1/8” adapter : N-35005 • Gage: 24177-160 (0 to 160 PSI, 23 mm)
24177-100 (0 to 100 PSI, 23 mm)
24177-060 (0 to 60 PSI, 23 mm)
Spare parts :
NON PLUG-IN
PLUG-IN
HOW TO ORDER
251
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Pressure regulators
OPERATIONAL BENEFITS
Series
Series PR46A
Sandwich-pressure regulator
1. Easy mounting: saves on installation costs in
comparison with inline regulators.
2. Compact all included units.
3. Large orifice provides high flow.
4. Various functions available.
5. Simple, reliable and solid design.
6. Single pressure regulator.
OPTIONS
PR46A-AAA A
A 0 to 120 PSI
B 0 to 80 PSI
C 0 to 30 PSI
Pressure range :
A Manual adjust with slotted screwdriver stem
B Manual adjust with adjusting knob
C Manual adjust with slotted screwdriver stem and locknut
Gauge
Gauge port (plugged)
For plug-in valves
PR46A-AAAA
For non plug-in valves
PR46A-BAAA
REGULATORS FOR "PLUG-IN" AND "NON PLUG-IN" VALVES
PR37A
PR42B
PR46A
PR47A
PR48B
PRA02A
PR92C
PR93A
PRA1A
PRA01A
PRP1A
PRA2D
PRP2B
PRA3C
PRP3B
0 Regulator only (No sandwich block)
Notes : gadges must be ordered separately, not included with regulator.
Recommended gage : 24165-150 (15 mm)
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
252
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series PR46A
Fluid :
Pressure range :
Regulating range :
Lubrication :
Filtration :
Temperature range :
Flow :
Compressed air, inert gases
0 to 120 PSI
0 to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F and 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
Cv 0,21
105.2
32.8
147.1
1/4" COMMONS
1/4" COMMONS
1"-11 1/2 NPS
82.5
32.9
103.1
IN
IN
EXH
EXH
COND
72.4
72.8
NON PLUG-IN
PLUG-IN
