301 Consult “Precautions” page 327 before use, installation or service of MAC Valves.. INTRINSICALLY SAFE CIRCUIT In order to use an intrinsically safe valve in a hazardous location, the installation must be in accordanc…
300
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Specifications for Intrinsically Safe Valves
301
52 series
304
400 series
304
92 series
305
Page
301
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
INTRINSICALLY SAFE CIRCUIT
In order to use an intrinsically safe valve in a hazardous location, the installation must be in accordance with the following installation diagram :
Intrinsically Safe Valves
There are 3 basic parts to an intrinsically safe circuit :
1. FIELD DEVICE
This is defined as the device that will be used in the hazardous location. In this case, the field device will be the intrinsically safe valve.
2. ASSOCIATED APPARATUS
This will be an energy limiting device also known as a barrier.
3. FIELD WIRING
Wiring used to connect the two above devices.
When the MAC intrinsically safe valves were tested for approval, they were tested and approved for the following atmospheres.
Class I, II, III
Division 1
Groups ; A, B, C, D, E, F, G
under the following parameters :
Vmax : 30 VDC
Imax : 175 ma
Ci : 0
Li : 0
Hazardous Location
Class I, II & III
Division 1
Group A, B, C, D,
E, F & G
FMRC Approved Single
or Dual Channel Positive
Polarity Intrinsic Safety
Barriers
Approved for
Class I, II, & III
Division 1
Group A, B, C, D,
E, F & G
Vmax = 30 v
Imax = 175 ma
Ci = 0
Li = 0
Control Room
Equipment
+ Red
- Black
Non-Hazardous Location
MAC Valve
Associated Apparatus
302
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Intrinsically Safe Valves
What this means is that the intrinsically safe valves were tested against each atmosphere with up to 30 VDC and 175 ma of current across the solenoid and found to still be safe. The other
two parameters are values to indicate how much energy can be stored or created by the valve :
Ci : Internal capacitance of the solenoid.
This indicates how much energy the solenoid is capable of storing.
Li : Internal inductance of the solenoid.
This indicates the solenoid’s ability to create or increase energy beyond what is supplied.
When applying an intrinsically safe valve in a hazardous location, a proper barrier must first be selected. The barrier selection process must first take into account the parameters the valve
was approved for and compared in the following way :
• Vmax must be greater than or equal to Voc of the barrier.
Voc = Voltage open circuit or maximum allowed out of the barrier
• Imax must be greater than or equal to Isc of the barrier.
Isc = Current short circuit or the maximum current allowed out of the barrier
• Ci plus field wiring must be less than Ca of the barrier.
Ca = Allowed capacitance
• Li plus field wiring must be less than La of the barrier.
La = Allowed inductance
When properly combined, the barrier will never allow more energy to the intrinsically safe valve than what it was tested and approved for.
The following page can be used as your guide to help ask the right questions when working with an intrinsically safe circuit. Also included is a partial list of intrinsically safe barriers that have
been tested with the MAC intrinsically safe valves.
