OPERATIONAL BENEFITS
Direct solenoid and solenoid pilot operated valves
HOW TO ORDER
91
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Series
46
Function Port size Flow (Max) Manifold mounting Series
4/2 1/8" - 5/32 O.D. Pressed-in 0.3 C
v
tube receptacles
Manifold base
“plug-in”
with PR & FC
1. Balanced poppet, immune to variations of
pressure.
2. Patented solenoid develops high shifting
forces.
3. Short stroke with high flow.
4. Higher forces result in lower wattages for
given flow.
5. Powerful return spring.
Port size
(Bottom ports only)
Valve less base
1/8” NPTF
5/32 O.D. Pressed-in tube receptacles
Model number
46A-L00-00-J
XX
P
-XXX
46A-LSA-AK-J
XX
P
-XXX
46A-LSF-AK-J
XX
P
-XXX
AB
AB
EXH IN
* Other options available, see page 317.
Note : AC voltage requires connector with rectifier.
Example : base only with regulator : 46A-0SA-AK.
End plate kit required (port size 1/4") : M-46003-01.
OPTIONS
46A-
L
SA-A
K
-J
XX
P-
XXX
0 Base only – no valve
L Base mount body
M Base mount body with gage port
K Regulator with adjusting knob & flow controls
F Regulator with slotted stem & flow controls
H Regulator with slotted stem with locknut & flow controls
Voltage
AA
120 VAC (5.4W)
DA
24 VDC (5.4W)
DB
12 VDC (5.4W)
DC
24 VDC (2.4W)
Manual operator
1
Non-locking recessed
2
Locking recessed
Electrical connection
FA
Base plug-in
FB
Base plug-in with diode
FG
Base plug-in with rectifier
J
XX
P-
XXX
*
(-G) Add “G” for ground
SOLENOID OPERATOR
®
XX X XX
78.0
4.4
94.3
Ø 4.3
4.0
52.5
18.6
16.5
32.8
22.5
9.5
34.2
19.0
79.0
95.5
69.2
TYP.
TYP.
PORT
1/8" GAGE
3/4"-14 NPSM
1/4" COMMONS
95.5
8.5
62.9
15.0
35.5
104.1
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
92
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series
46
Fluid :
Pressure range :
Lubrication :
Filtration :
Temperature range :
Flow :
Coil :
Voltage range :
Protection :
Power :
Response times :
Compressed air, vacuum, inert gases
Vacuum to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F and 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
1.8W : (0.20 C
v
) – 2.4W : (0.20 C
v
) – 5.4W : (0.30 C
v
)
Class A continuous duty, #22 AWG x 12 base leads
-15% to +10% of nominal voltage
Consult factory
5.4W – 2.4W – 1.8W
Energize : 7.20 ms
De-energize : 4.20ms
• BSPP threads
• Inlet isolator : 28501 • Exhaust isolator : 28502 • Valve cover plate : M-46002 • Tie rod (x2) : 79443
• Replacement regulators : PR46A-0AAA (slotted stem)
PR46A-0BAA (adjusting knob)
PR46A-0CAA (slotted stem with locknut)
• PR46A-xxxA
A 0 to 120 PSI
B 0 to 80 PSI
C 0 to 30 PSI
Options :
Spare parts :
Regulating range options :
93
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Individual mounting Series
Direct solenoid and solenoid pilot operated valves
SERIES FEATURES
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Sub-base
non “plug-in”
Sub-base
“plug-in”
Sub-base/
manifold base
non “plug-in”
with latching
solenoid
Sub-base/
manifold base
“plug-in”
with latching
solenoid
Manifold base
“plug-in”
Sub-base/
manifold base
non “plug-in”
with latching
solenoid
Sub-base/
manifold base
“plug-in”
with latching
solenoid
Manifold base
non “plug-in”
Series
42
Manifold mounting
• High force MACSOLENOID
®
.
• Integral 4-way pilot design.
• Single or dual pressure.
• Internal or external pilot.
• Single or double solenoid.
• 2 or 3 position.
• Rectified AC voltage.
• Latching solenoid technology.
32145
Manual operator
Integral 4-way pilot
Solenoid
Air return
Bonded spool
