7 Consult “Precautions” page 327 before use, installation or service of MAC Valves.. Introduction Let us show you via high performance demonstration kits and animated software, HOW MAC’S PERFORMANCE ADVANTAGES HELP MAKE …

Consult “Precautions” page 327 before use, installation or service of MAC Valves..

Introduction

MAC DISTRIBUTORS NETWORK

KEEPING YOUR MACHINES RUNNING AROUND THE CLOCK AROUND THE WORLD

45 countries

200 service centers

1000 factory certified application specialists

3500 employees

$ 50 million inventory

• 30 years experience

• Local support

• Globally linked network

• Special solutions

• Global customer partnership

ACT LOCAL

Consult “Precautions” page 327 before use, installation or service of MAC Valves..

Introduction

Let us show you via high performance demonstration kits and animated software,

HOW MAC’S PERFORMANCE ADVANTAGES HELP MAKE YOUR EQUIPMENT MORE RELIABLE - FASTER - MORE REPEATABLE.

Other MAC VALVE literature:

DESCRIPTION CATALOG NUMBER

CURRENT TECHNOLOGY 999CTCB

BUILDING BLOCKS BROCHURE 999ADVB

CIRCUIT BAR CATALOG 999CBCA

PROPORTIONAL VALVE CATALOG 999PPCB

CATALOG CD 999CCDB

SERIAL INTERFACE PRODUCTS 9999SI

MACONNECT SYSTEM CONSULT FACTORY

999CTCB 999ADVB 999CBCA 999PPCB

TLD

Traveling Lab Demonstration measures critical valve

performance characteristics -

Shifting forces, Response

Time, Speed, Repeatability and Flow.

Animation

Animated Software shows inner workings of various Air

Valves Designs -

Powerful educational tool for learning

about how air valves function.

PLD

Proportional Lab Demonstration measures critical

proportional regulation characteristics -

Response Time,

Accuracy, Hysterisis, Repeatability and Flow.

Consult “Precautions” page 327 before use, installation or service of MAC Valves..

MAC Valves 18 month guarantee plus lifetime coil guarantee

The MAC Valves organization has established a reputation over many years for fulfilling the needs and requirements of the users of its products.

All MAC Valves are quality products specifically designed and built for long and rugged service. Therefore, all valves appearing in this catalog are guaranteed

for a period of eighteen months from the original date of shipment from our factory. In addition to this eighteen month Guarantee, MAC Valves, Inc. guarantees

the electrical coils on every one of the valves listed in this catalog for life. LIMITATION OF GUARANTEE: This Guarantee is limited to the replacement or

rebuilding of any valve which should fail to operate properly. Valves, under the MAC Guarantee, must be returned (with or without bases) transportation prepaid

and received at our factory within the Garantee period. They will be returned to the customer at the expense of MAC Valves, Inc., and will carry the same

guarantee as provided under the Flat Rate Rebuild Program. DISCLAIMER OF GUARANTEE: No claims for labor, material, time, damage or transportation are

allowable nor will any valve be replaced or rebuilt under this guarantee which has been damaged by the purchaser not in the normal course of its use and

maintenance during the warranty period. The guarantee does not apply to loss or damage caused by fire, theft, riot, explosion, labor dispute, act of God, or

other causes beyond the control of MAC Valves, Inc. MAC Valves, Inc. shall in no event be liable for remote, special or consequential damages under the MAC

Guarantee, nor under any implied warranties, including the implied warranty of merchantability.

The above Guarantee is our manner of extending the engineering and service resources of the MAC Valves, Inc. organization to assure our customer long, and

continued satisfaction.

The flat rate rebuild program

Valves no longer covered by the MAC Guarantee can be rebuilt under the Flat Rate Rebuild program. Our constant research and testing program is dedicated to

extending the life of our valves and making them even more reliable under the most adverse operating conditions. Valves returned under this program are

completely disassembled , inspected, rebuilt to current operating standards wherever possible, tested and returned within a few weeks for a nominal flat rate

charge. All rebuilt valves carry for 90 days from date of shipment from our factory the same guarantee as provided for new valves.

Pneumatic functions

All valves inside the MAC product range allow for multiple pneumatic functions.

Direct solenoid and solenoid pilot operated valves could be used as 2 ways, 3 ways (NO, NC) or 4 ways.

When plugging one orifice to achieve a 2 way function (or 3 way), it will not affect the valve operation.

Introduction

10 0

MONTHS

WARRANTY

PRODUCTION

TESTED

• Direct solenoid valves 3 ways : universal

The following functions are available

- 3 ways NC

- 3 ways NO

- 2 ways NC

- 2 ways NO

- Selector

- Divertor

• Direct solenoid valves 4 ways :

The following functions are available

- 4 ways

- 3 ways NC

- 3 ways NO

- 2 ways NC

- 2 ways NO

- Divertor

• Pilot operated valves 3 ways :

The following functions are available

- 3 ways NC

- 3 ways NO

- 2 ways NC

- 2 ways NO

- Selector : the highest pressure is connected to the IN port; the lowest pressure

is connected to the EXH port. (Use external pilot when the highest pressure

is less than 25 PSI)

- Divertor (consult factory)

• Pilot operated valves 4 & 5 ways :

The following functions are available

- 4 or 5 ways

- 3 ways NC

- 3 ways NO

- 2 ways NC

- 2 ways NO

- Selector (except 3 positions)

- Divertor (consult factory).

EVERY VALVE FULLY TESTED PRIOR TO SHIPMENT
