HOW TO ORDER 257 Consult “Precautions” page 327 before use, installation or service of MAC Valves.. Pressure regulators OPERATIONAL BENEFITS Series PR37A PR42B PR46A PR47A PR48B PRA02A PR92C PR93A PRA1A PRA01A PRP1A PRA2…
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
256
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series PR48B
Fluid :
Pressure range :
Regulating range :
Lubrication :
Filtration :
Temperature range :
Flow :
Compressed air, inert gases
0 to 120 PSI
0 to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F to 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
0.8 C
v
2
4
4
222
4
4
3
5
1
EP
COND
1
3
5
EP
134.0
144.5
226.4
212.3
• Pressure regulator (less sandwich block) : PR48B-C0AA (knob), PR48B-F0AA (screwdriver slot), PR48B-J0AA (screwdriver slot with locknut)
• Gage: 24177-160 (0 to 160 PSI, 23 mm)
24177-100 (0 to 100 PSI, 23 mm)
24177-060 (0 to 60 PSI, 23 mm)
Spare parts :
NON PLUG-IN
PLUG-IN
HOW TO ORDER
257
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Pressure regulators
OPERATIONAL BENEFITS
Series
PR37A
PR42B
PR46A
PR47A
PR48B
PRA02A
PR92C
PR93A
PRA1A
PRA01A
PRP1A
PRA2D
PRP2B
PRA3C
PRP3B
Series PR92C
Sandwich pressure regulator with air pilot adjust
1. Easy mounting: saves on installation costs in
comparison with inline regulators.
2. Compact all-included units.
3. Large orifice provides high flow.
4. Various functions available.
5. Simple, reliable and solid design.
Gage
Gage port only (plugged)
Gage with face
perpendicular
to manual operator
Gage with face
parallel to
manual operator
Regulator A end
Single pressure
PR92C-EAAA
PR92C-EABA
PR92C-EACA
Regulator B end
Single pressure
PR92C-EBAA
PR92C-EBBA
PR92C-EBCA
Regulator A
*
end with
by-pass end plate B end
PR92C-ECAA
PR92C-ECBA
PR92C-ECCA
Regulator B
*
end with
by-pass end plate A end
PR92C-EDAA
PR92C-EDBA
PR92C-EDCA
Regulator
*
both ends
PR92C-EEAA
PR92C-EEBA
PR92C-EECA
REGULATORS FOR "PLUG-IN" VALVES
PR92C-
E
XXX
PLUG-IN OPTIONS
F for double solenoid valve
Note: above models are coded for use with single solenoid valves
*
For use with dual pressure valves.
Gage
Gage port only (plugged)
Gage with face
perpendicular
to manual operator
Gage with face
parallel to
manual operator
Regulator A end
Single pressure
PR92C-GAAA
PR92C-GABA
PR92C-GACA
Regulator B end
Single pressure
PR92C-GBAA
PR92C-GBBA
PR92C-GBCA
Regulator A
*
end with
by-pass end plate B end
PR92C-GCAA
PR92C-GCBA
PR92C-GCCA
Regulator B
*
end with
by-pass end plate A end
PR92C-GDAA
PR92C-GDBA
PR92C-GDCA
Regulator
*
both ends
PR92C-GEAA
PR92C-GEBA
PR92C-GECA
REGULATORS FOR "NON PLUG-IN" VALVES
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
258
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series PR92C
Fluid :
Pressure range :
Regulating range :
Lubrication :
Filtration :
Temperature range :
Flow :
Compressed air, inert gases
0 to 120 PSI
0 to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F to 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
0.8 C
v
EX
IN
VAC TO 120 PSI
WATTS
ELECTRICAL
MODEL
MODIF.
AUCKLAND,N.Z.
LIEGE,BELGIUM
WIXOM,MI. USA
EP
GAGE
PILOT
202.56
145.88
MANUAL
OPERATOR
W/ DOUBLE REGULATOR
APPROX.
APPROX.
47.5
APPROX.
135.0
• R-92003 : regulator end plate kit • Gage kit 0 - 160 PSI: N-92006-01
• R-92003-01: regulator by-pass end plate kit
• Pressure regulator (less sandwich block) : PR92C-H0AA
Spare parts :
