Edition 5.0
H24 Head Repair Training Text for Service Engineers
Replacing the Q-axis motor
Chapter 5 - Replacing the Q-axis Motor
The Q-axis motor replacement is explained below.
Note: Be sure to prepare a replacement motor with terminals attached.
Note: Q-axis proper data measurement is required following replacement of the Q-
axis motor.
5.1 Removing the Q-axis Motor
1. Remove the following cover.
2. Disconnect the connectors from the control board.
FK-9F50-08-0E 5-1 FUJI MACHINE MFG. CO., LTD.
