18
WinMCS_Manual(ENG) rev1.0
Koh Young Technology Inc.
Step Zoom Command
1. H SVON :
Head Motor Servo On
2. H SVOFF :
Head Motor Servo Off
3. L SVON :
Lens Motor Servo On
4. L SVOFF :
Lens Motor Servo Off
5. Position :
Current positions of Head, Lens Motor
6. Homing :
Head and Lens Motor Homing
7. Aging Start :
Head and Lens Motor Aging Start
8. Aging Stop :
Head and Lens Motor Aging Stop
9. Zoom1Pos :
Moving to the first Zoon position of Head and Lens
10. Zoom2Pos :
Moving to the second Zoon position of Head and Lens
11. Zoom3Pos :
Moving to the third Zoon position of Head and Lens
12. Zoom4Pos :
Moving to the forth Zoon position of Head and Lens
13. Zoom5Pos :
Moving to the fifth Zoon position of Head and Lens
19
Service Manual
Koh Young Technology Inc.
Step Zoom Jog
1. Move Head:
It moves the head motor as much as the input value
ex) 69 + enter: Head motor moves as much as 69mm.
2. Move Lens:
It moves the lens motor as much as the input value
ex) 30 + Lens: Lens Motor moves as much as 30mm.
ZOOM Axis Status & IO Status
1. HEAD STATE:
It displays the state of Head Motor (Servo On, Limit(+), Run, EMG, Origin, Done)
2. LENS STATE:
It displays the state of Lens Motor (Servo On, Limit(+), Run, EMG, Origin, Done)
3. HEAD IO:
It checks whether the motion of Head Motor is completed or not.
4. LENS IO:
It checks whether the motion of Head Motor is completed or not.
5. HEAD HOME:
Head Motor Homing
6. LENS HOME:
Lens Motor Homing
20
WinMCS_Manual(ENG) rev1.0
Koh Young Technology Inc.
3.6. Laser Mode
N
N
o
o
t
t
e
e
For more information about Laser mode, see Laser Setting Manual.
