5 Annex

5.3 Excerpt from User Manual

124 Assembly Instructions / Montageanleitung SIPLACE X-Series S Smart Pin Support 05/2019

5.3.1.2 Handling Error Cases

Error message for support pin

If the support pin cannot be found (i.e. because it has slipped) or a fiducial for the support pin can-

not be detected (i.e. because soiled) you will be asked to confirm that the support pin has been

manually removed.

► Fix the error and restart the measurement.

The support pin is measured, the position is saved and the support pin is picked up again.

If you remove the support pin manually instead and confirm this, the calibrating procedure is can-

celed.

Error message for pin magazine(s)

If the station detects that a support pin is present in the garage, you are prompted to remove the

support pin.

► Remove the support pin from the garage.

► Confirm the message.

After that, the pin magazine calibration continues.

Error message for lifting table(s)

If other calibration steps than those for the Smart Pin Support function are performed and a map-

ping plate is required, a general message will be displayed that prompts you to remove support

pins from the lifting table. If support pins should be present on the lifting table, the calibration will be

canceled with a corresponding message.

► Remove the support pins from the lifting table.

► Confirm via the appropriate button that the support pins were removed and then restart the

measurement.
