5 Materials 5-1 5 Materials Standard Accessories Replacement Parts
4 Electrical Section
4-32
Computer Virus Prevention and Treatment
Recently, reports of computer virus infection on our machines are increasing. It’s supposed that because of
using high capacity USB memory stick for data backup and restore. First, prevention of infecting computer
virus is important but if the machine is infected already the virus must be eliminated by an anti-virus
software. This document describes the examples of prevention against computer virus and the treatment for
the machines that virus infected.
Computer Virus Prevention
We check every machine with the latest virus checker as one of the shipping inspection items. None of our
machine is infected any virus when they are shipped.
The most of infection route is the internet generally. Our machine has no capability to access internet and
no possibility of direct infection. The possibility is a secondary infection from a computer that is connected
with our machines through LAN connection. Common external memory storage such as USB memory stick
with the computer also can be a carrier of viruses.
Virus checker software cannot be installed in our machines. Followings are suggested for the prevention.
* Do not connect LAN with computer that can access the internet.
* Install virus checker software in the computer that shares storages for placement programs.
* Do virus scan the external memory storage like USB memory frequently by the virus checker.
5 Materials
5-1
5
Materials
Standard Accessories
Replacement Parts
5 Materials
5-2
Standard Accessories
Part Name Part No. Qty. Remarks
Support Pin (Magnet type)
PIN,MAGNET ASSY.
Signal Cable (Std.)
HNS. PRE-PROCESS
LG0-M56K0-10X 1
4m
Select standard or SMEMA
Signal Cable (Std.)
HNS. POST-PROCESS
LG0-M56K0-20X 1
Signal Cable (SMEMA)
HNS.SMEMA - SMEMA
LG0-M56K0-00X
LG0-M56K0-61X
WRENCH SET LG0-M89A3-00X
SCREW DRIVER(-) LG0-M89A2-00X
LENS CLEANER SET LG0-M89A4-00X 1
GREASE SILICON LG0-M89AB-00X 1
LCD MONITOR LC8-M6571-00X 1
KEYBOARD ASSY.(ENG) KW3-M5150-60X 1 IBM AT, PS/2 compatible
MOUSE
KW3-M5169-04X 1
With wheel, PS/2,
Mini DIN 6pin
RECOVERY KIT LE6-M4512-XXX 1
NOZZLE CLEANER KIT LG0-M5J00-00X
COUPLER LG0-M89A1-00X
【NOTE】
1) Select the communication cable from standard or SMEMA type.
2) I BM. A T ､P S / 2 Compatible
3) P S / 2 Serial Mouse Interface Connect ( Mini D I N 6 pin Male)
