4 Electrical Section
4-15
Serial DI Map
■ Device 2
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0000h 0 Device No. Bit 0 0004h 0 SERVO (F)/READY (F)
1 Device No. Bit 1 1 CANCEL (F)/RESET (F)
2 Device No. Bit 2 2 START (F)
3 Device No. Bit 3 3 CYCLE STOP (F)/ STOP (F)
4 Device Added Information Bit 0 4 RECOVERY (F)/CLEAR (F)
5 Device Added Information Bit 1 5
6 Device Added Information Bit 2 6
7 Output Register Value Bit 0 7 DOCKING (F) / (Right Front)
0001h 0 Output Register Value Bit 1 0005h 0
1 Output Register Value Bit 2 1 Tape Cutter Close (Right Front)
2 Output Register Value Bit 3 2 Tape Cutter Close (Left Front)
3 Output Register Value Bit 4 3 Tape Cutter Close ((Right Rear)
4 Input Register Value Bit 0 4 Tape Cutter Close (Left Rear)
5 Input Register Value Bit 1 5 Y1 Regenerative Resistor Thermal Alarm
6 Input Register Value Bit 2 6 Y2 Regenerative Resistor Thermal Alarm
7 Input Register Value Bit 3 7 X Regenerative Resistor Thermal Alarm
0002h 0 Y-axis OR- 0006h 0 SERVO (R)/ RESET (R)
1 Y-axis OR+ 1 CANCEL (R) / RESET (R)
2 2 START (R)
3 3 CYCLE STOPE (R) / STOP (R)
4 4 RECOVERY (R) / CLEAR (R)
5 5
6 UPS Under backup 6
7 UPS Battery Low 7 DOCKING (Left Rear)
0003h 0 Board Available Input 0007h 0
1 Ready Input 1
CTF(Right Rear) Power Relay ON
2 Regenerative Resistor 1 Thermo Alarm 2
3 Regenerative Resistor 2 Thermo Alarm 3
CTF(Right Rear) Connector Check
4 Regenerative Resister 3 Thermo Alarm 4
5 5
6 6
7
Fixed Camera Illumi. Trigger Invalid
7
4 Electrical Section
4-16
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0008h 0 000Ch 0 Entrance Sensor
1 1 Entrance Buffer Arrival
2 2 Board Stopper On
3 3 Board Stopper Off
4 CFB(F) / (Left Front) Lock (R) 4 Exit Sensor / Exit Buffer Arrival
5 CFB(F) / (Left Front) Lock (L) 5 Exit Buffer Slowdown
6 CFB(F) / (Left Front) Check 6 Board Stopper On 2
7 7 Board Stopper Off 2
0009h 0 CFB(Left Rear) Lock (R) 000Dh 0 Main Clamp Up / Push-up Pin Up
1 CFB(Left Rear) Lock (L) 1 Push-up Pin Down
2 CFB (Left Rear) Check 2 Quick Clamp Down (Front)
3 3
4 4 Quick Clamp Down (Rear)
5 5
Support Pins under Conveyor Rail
6 6
7 7
RTS-1(R) sensor
000Ah 0 ENABLE (F) / ACTIVE (F) 000Eh 0
1 ENABLE (R) / ACTIVE (R) 1
2
CTF(Right Rear) Positioning
2 ANC A Open
3 CTF (Left Rear) Insert Complete (L) 3 ANC A Close
4 CTF (Left Rear) Insert Complete (R) 4 Entrance Buffer Slowdown
5
Dot Station Paper Shortage
5 Main Conveyor Slow down 2
6 6
7 7 Main Conveyor Arrival
000Bh 0 000Fh 0 Main Conveyor Slowdown
1 1 Main Conveyor Arrival 2
2 Conveyor 1 Alarm 2
3 Conveyor 2 Alarm 3
4 Conveyor 3 Alarm 4
5 5
6 6
7 7
4 Electrical Section
4-17
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0010h 0 EMG (F) 0012h 0 Fan (Bottom 1) Lock
1 Front Cover OPEN Detection 1 Fan (Bottom 2) Lock
2 Cover Lock On (F) 2 Fan (Top 1) Lock
3 3 Fan (Top 2) Lock
4 EMG (R) 4 Fan (Regenerative Resister 1) Lock
5 Rear Cover OPEN Detection 5 Fan (Regenerative Resister 2) Lock
6 Cover Lock On (R) 6
7 7 Fan (Y1 Motor) Lock
0011h 0 SERVO (1:ON) / SERVO ON State 0013h 0 Fan (Y2 Motor) Lock
1 Air Pressure Down (failure) 1 Fan (X Motor) Lock
2 2 Fan (X Beam) Lock
3 3
4 4
5 5
6 6
7 7
■ Device 4
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0000h 0 Device No. Bit 0 0002h 0 AZ-axis 1 OR+
1 Device No. Bit 1 1 AZ-axis 2 OR+
2 Device No. Bit 2 2 AZ-axis 3 OR+
3 Device No. Bit 3 3 AZ-axis 4 OR+
4 Device Added Information Bit 0 4 AZ-axis 5 OR+
5 Device Added Information Bit 1 5 AZ-axis 6 OR+
6 Device Added Information Bit 2 6 OR-1(X)
7 Output Register value Bit 0 7 OR+1(X)
0001h 0 Output Register value Bit 1 0003h 0
1 Output Register value Bit 2 1
2 Output Register value Bit 3 2
3 Output Register value Bit 4 3
4 Input Register Value Bit 0 4
Dispense Head 1 Fluid Shortage
5 Input Register Value Bit 1 5 Dispense Head 2 Fluid Shortage
6 Input Register Value Bit 2 6 Dispense Head 3 Fluid Shortage
7 Input Register Value Bit 3 7 Dispense Head 4 Fluid Shortage
