1
About This Manual
Thank you for purchasing our dispenser.
This manual functions as maintenance guide. Please be sure to read this manual before servicing the unit.
After reading this manual, keep it handy so that it will be available at any time.
Features:
z Functions of the Unit are classified and then detailed explanation, limited condition and advice for
operation are described for each function.
z This manual consists of five chapters, Installation, Periodical Check, Mechanical Section, Electrical
Section and Materials.
z Terms are expounded in the note as necessary. .
z It is easier to retrieve information by referring to index attached at the end of this manual.
Style Conventions:
z Example: Shows a major example.
z Menu: Shows a function from higher hierarchy in order.
[Example] Edit > Program Edit > File > Board
z Action: Shows the procedure, operate following the order.
z Item: Shows items of MMI Window.
The log item name is described as “ ……..”
z Note: Shows an important point that calls for attention.
z
)
Shows the reference page or manual.
[ ]: Tab titles and sub-titles in the MMI windows are enclosed in these brackets.
< >: Buttons in the MMI windows are enclosed in these brackets.
“ “: User entries for the MMI windows are enclosed in double quotations.
Controls on the machine control panel are boxed.
2
z An especially important point is highlighted as shown below:
Example:
The surface of the scan camera mirror is very sensitive. Be sure to treat the
mirror with extra caution.
z Dangerous operations are noted in two levels: Warning and Caution.
Warning:
Failing to comply with the instructions suggested in a “Warning” will lead to a fatal injury or a death. (A
“fatal injury” means an injury, a scald, an electric shock, or a bone fracture,
leading to a persisting aftereffect, also means one requiring a long-term hospital treatment as an inpatient or
an outpatient.) An example follows:
Example:
When performing teach entry in which driving axes are allowed to move, do not stick head,
hands, or other parts of the body inside the unit. Serious injury can result. Also make sure
non-operators are a safe distance from the machine.
Caution:
Failing to comply with the action suggested in a “Caution” will lead to a serious injury or a machine
damage. (A “serious injury” means an injury, a scald, or an electric shock, not requiring a long-term
hospital treatment as a inpatient or an outpatient.) An example follows:
Example:
Before starting teach entry, make sure no foreign obstacles are left in the unit or tray feeder.
Otherwise, costly machine damage can occur.
Note: According to condition of optional equipments, MMI screen of your machine might be deferent
from MMI screen shown in this manual.
Warning
Caution
3
Safety Guidelines
To prevent injury or machine damage in using the unit, follow the safety guidelines stated below:
■ General
Only trained personnel, who are thoroughly familiar with the unit, must use the unit and enter work area.
To prevent electric shock and machine damage, never do tasks such as moving the machine, connect the
machine to other equipment, or servicing the machine when the power is on.
To prevent electric shock and machine damage, never touch terminals of electric components when the
power is on. Electric-shock labels are affixed to the machine covers under which the live electrical parts are
placed.
To prevent electric shock, ground the unit.
Press immediately the emergency stop switch when the machine operates improperly.
To prevent electric shock, do not operate the unit by wet hands.
■ Operation
The head assembly of the unit moves at high speeds. To prevent injuries, do not enter head, hands and a part
of your body inside the operating unit.
To prevent electric shock and machine damage, do not operate the unit with live parts exposed.
To prevent electric shock and machine damage, do not touch parts in the control unit.
Turn off the main switch, if power failure occurs, to prevent sudden restarting that may cause personal
injury or machine damage.
In teaching mode, axes will move following your operation, to prevent injuries, do not enter head, hands
and a part of the body inside the operating unit. And, confirm the safety for people around the unit and tray
feeder.
The mounting heads will move when scanning the nozzle stations, to prevent injures, do not enter head,
hands and a part of the body inside th during e operating machine. And, confirm the safety for people
around the unit and tray feeder.
When doing Tray Teach, the mounting heads will move, to prevent injures, do not enter head, hands , and a
part of the body inside the operating machine. And, confirm the safety for people around the unit and tray
feeder.
The mounting heads will move when executing ASJ, to prevent injures, do not enter head, hands and a part
of the body when starting ASJ to prevent injures. And, confirm the safety for people around the unit and
tray feeder.
Warning
