4 Electrical Section

4-18

Address

Bit

No.

Signal Name Address

Bit

No.

Signal Name

0004h 0 Air Pressure: Head A1 Bit 0 0008h 0 Air Pressure ; Head A3 Bit 0

1 Air Pressure: Head A1 Bit 1 1 Air Pressure ; Head A3 Bit 1

2 Air Pressure: Head A1 Bit 2 2 Air Pressure ; Head A3 Bit 2

3 Air Pressure: Head A1 Bit 3 3 Air Pressure ; Head A3 Bit 3

4 Air Pressure: Head A1 Bit 4 4 Air Pressure ; Head A3 Bit 4

5 Air Pressure: Head A1 Bit 5 5 Air Pressure ; Head A3 Bit 5

6 Air Pressure: Head A1 Bit 6 6 Air Pressure ; Head A3 Bit 6

7 Air Pressure: Head A1 Bit 7 7 Air Pressure ; Head A3 Bit 7

0005h 0 Air Pressure: Head A1 Bit 8 0009h 0 Air Pressure ; Head A3 Bit 8

1 Air Pressure: Head A1 Bit 9 1 Air Pressure ; Head A3 Bit 9

2 Air Pressure: Head A1 Bit 10 2 Air Pressure ; Head A3 Bit 10

3 Air Pressure: Head A1 Bit 11 3 Air Pressure ; Head A3 Bit 11

4 Air Pressure: Head A1 Bit 12 4 Air Pressure ; Head A3 Bit 12

5 Air Pressure: Head A1 Bit 13 5 Air Pressure ; Head A3 Bit 13

6 Air Pressure: Head A1 Bit 14 6 Air Pressure ; Head A3 Bit 14

7 Air Pressure: Head A1 Bit 15 7 Air Pressure ; Head A3 Bit 15

0006h 0 Air Pressure: Head A2 Bit 0 000Ah 0 Air Pressure ; Head A4 Bit 0

1 Air Pressure: Head A2 Bit 1 1 Air Pressure ; Head A4 Bit 1

2 Air Pressure: Head A2 Bit 2 2 Air Pressure ; Head A4 Bit 2

3 Air Pressure: Head A2 Bit 3 3 Air Pressure ; Head A4 Bit 3

4 Air Pressure: Head A2 Bit 4 4 Air Pressure ; Head A4 Bit 4

5 Air Pressure: Head A2 Bit 5 5 Air Pressure ; Head A4 Bit 5

6 Air Pressure: Head A2 Bit 6 6 Air Pressure ; Head A4 Bit 6

7 Air Pressure: Head A2 Bit 7 7 Air Pressure ; Head A4 Bit 7

0007h 0 Air Pressure: Head A2 Bit 8 000Bh 0 Air Pressure ; Head A4 Bit 8

1 Air Pressure: Head A2 Bit 9 1 Air Pressure ; Head A4 Bit 9

2 Air Pressure: Head A2 Bit 10 2 Air Pressure ; Head A4 Bit 10

3 Air Pressure: Head A2 Bit 11 3 Air Pressure ; Head A4 Bit 11

4 Air Pressure: Head A2 Bit 12 4 Air Pressure ; Head A4 Bit 12

5 Air Pressure: Head A2 Bit 13 5 Air Pressure ; Head A4 Bit 13

6 Air Pressure: Head A2 Bit 14 6 Air Pressure ; Head A4 Bit 14

7 Air Pressure: Head A2 Bit 15 7 Air Pressure ; Head A4 Bit 15

4 Electrical Section

4-19

Address

Bit

No.

Signal Name Address

Bit

No.

Signal Name

000Ch 0 Air Pressure ; Head A5 Bit 0 0011h 0 Laser Sensor 1 Data Bit 8

1 Air Pressure ; Head A5 Bit 1 1 Laser Sensor 1 Data Bit 9

2 Air Pressure ; Head A5 Bit 2 2 Laser Sensor 1 Data Bit 10

3 Air Pressure ; Head A5 Bit 3 3 Laser Sensor 1 Data Bit 11

4 Air Pressure ; Head A5 Bit 4 4 Laser Sensor 1 Data Bit 12

5 Air Pressure ; Head A5 Bit 5 5 Laser Sensor 1 Data Bit 13

6 Air Pressure ; Head A5 Bit 6 6 Laser Sensor 1 Data Bit 14

7 Air Pressure ; Head A5 Bit 7 7 Laser Sensor 1 Data Bit 15

000Dh 0 Air Pressure ; Head A5 Bit 8 0012h 0 Laser Sensor 2 Data Bit 0

1 Air Pressure: Head A5 Bit 9 1 Laser Sensor 2 Data Bit 1

2 Air Pressure: Head A5 Bit 10 2 Laser Sensor 2 Data Bit 2

3 Air Pressure: Head A5 Bit 11 3 Laser Sensor 2 Data Bit 3

4 Air Pressure: Head A5 Bit 12 4 Laser Sensor 2 Data Bit 4

5 Air Pressure: Head A5 Bit 13 5 Laser Sensor 2 Data Bit 5

6 Air Pressure: Head A5 Bit 14 6 Laser Sensor 2 Data Bit 6

7 Air Pressure: Head A5 Bit 15 7 Laser Sensor 2 Data Bit 7

000Eh 0 Air Pressure: Head A6 Bit 0 0013h 0 Laser Sensor 2 Data Bit 8

1 Air Pressure: Head A6 Bit 1 1 Laser Sensor 2 Data Bit 9

2 Air Pressure: Head A6 Bit 2 2 Laser Sensor 2 Data Bit 10

3 Air Pressure: Head A6 Bit 3 3 Laser Sensor 2 Data Bit 11

4 Air Pressure: Head A6 Bit 4 4 Laser Sensor 2 Data Bit 12

5 Air Pressure: Head A6 Bit 5 5 Laser Sensor 2 Data Bit 13

6 Air Pressure: Head A6 Bit 6 6 Laser Sensor 2 Data Bit 14

7 Air Pressure: Head A6 Bit 7 7 Laser Sensor 2 Data Bit 15

000Fh 0 Air Pressure: Head A6 Bit 8 0014h 0 Teach Camera Illumi, Trigger Invalid

1 Air Pressure: Head A6 Bit 9 1

2 Air Pressure: Head A6 Bit 10 2

3 Air Pressure: Head A6 Bit 11 3

4 Air Pressure: Head A6 Bit 12 4 Fan (Head Unit) Lock

5 Air Pressure: Head A6 Bit 13 5

6 Air Pressure: Head A6 Bit 14 6

7 Air Pressure: Head A6 Bit 15 7

0010h 0 Laser Sensor 1 Data Bit 0

1 Laser Sensor 1 Data Bit 1

2 Laser Sensor 1 Data Bit 2

3 Laser Sensor 1 Data Bit 3

4 Laser Sensor 1 Data Bit 4

5 Laser Sensor 1 Data Bit 5

6 Laser Sensor 1 Data Bit 6

7 Laser Sensor 1 Data Bit 7

4 Electrical Section

4-20

■ Device 8

Address

Bit

No.

Signal Name Address

Bit

No.

Signal Name

0000h 0 Device No. Bit 0 0002h 0 BOARD (Left Front) ID0

1 Device No. Bit 1 1 BOARD (Left Front) ID1

2 Device No. Bit 2 2 BOARD (Left Front) ID2

3 Device No. Bit 3 3 BOARD (Left Front) ID3

4 Device Added Information Bit 0 4 BOARD (Left Front) ID4

5 Device Added Information Bit 1 5 BOARD (Left Front) ID5

6 Device Added Information Bit 2 6 BOARD (Left Front) ID6

7 Output Register Value Bit 0 7 BOARD (Left Front) ID7

0001h 0 Output Register Value Bit 1 0003h 0 BOARD (Left Front) ID8

1 Output Register Value Bit 2 1 BOARD (Left Front) ID9

2 Output Register Value Bit 3 2 BOARD (Left Front) ID10

3 Output Register Value Bit 4 3 BOARD (Left Front) ID11

4 Input Register Value Bit 0 4 BOARD (Left Front) ID12

5 Input Register Value Bit 1 5 BOARD (Left Front) ID13

6 Input Register Value Bit 2 6 BOARD (Left Front) ID14

7 Input Register Value Bit 3 7 BOARD (Left Front) ID15

■ Device 10

Address

Bit

No.

Signal Name Address

Bit

No.

Signal Name

0000h 0 Device No. Bit 0 0002h 0 BOARD (Left Rear) ID0

1 Device No. Bit 1 1 BOARD (Left Rear) ID1

2 Device No. Bit 2 2 BOARD (Left Rear) ID2

3 Device No. Bit 3 3 BOARD (Left Rear) ID3

4 Device Added Information Bit 0 4 BOARD (Left Rear) ID4

5 Device Added Information Bit 1 5 BOARD (Left Rear) ID5

6 Device Added Information Bit 2 6 BOARD (Left Rear) ID6

7 Output Register Value Bit 0 7 BOARD (Left Rear) ID7

0001h 0 Output Register Value Bit 1 0003h 0 BOARD (Left Rear) ID8

1 Output Register Value Bit 2 1 BOARD (Left Rear) ID9

2 Output Register Value Bit 3 2 BOARD (Left Rear) ID10

3 Output Register Value Bit 4 3 BOARD (Left Rear) ID11

4 Input Register Value Bit 0 4 BOARD (Left Rear) ID12

5 Input Register Value Bit 1 5 BOARD (Left Rear) ID13

6 Input Register Value Bit 2 6 BOARD (Left Rear) ID14

7 Input Register Value Bit 3 7 BOARD (Left Rear) ID15
