1-50
0802-002
(6) AttachthecutunitxingJig.
WARNING
Pay close attention to the cutter blade during the maintenance
work.
•
Lack of attention will result in a hand injury, etc.
Wear gloves and take the greatest care in performing the work.
•
Besuretoattachthexingjigtothecutunitduringthe
maintenance work for safety purposes.
(7) Detach the urethane clamp from the tape clamp.
(8) Peel off the double-faced tape of a new urethane clamp and
attach a new urethane clamp to the tape clamp.
New Urethane Clamp
Old Urethane Clamp
Double-Faced Tape Side
View (Attachment Direction)
from Side Face
Cut Unit
Fixing Jig
Fig. 4A49
4.3 Replacement of Fluorine Sheet and Urethane Clamp
1-51
0709-001
(9) Loosenthescrewsoftapeguideanddetachthe
uorinesheet
andtheplate.Afterthat,replace
theuorinesheetwithanew
one.
Tape Guide
New Fluorine Sheet
Old Fluorine Sheet
Fig. 4A50
(10)Attachtheuorinesheetandtheplatetothetapeguide.
At this time, conrm that the uorine sheet is put between the tape
clamps.
(1
1)Detachthecutunitxingjig.
(12) Attach the tape guide and the transparent cover.
(13)
Close the cover, power the machine, and perform a zeroing
operation.
(14) Select the [Round trip] button in the "Mode" group box in the
"CUTTER ADJ" window to shuttle the cutters.
(OperationSequence:[MAINT]onMainMenu
→[UNITADJ.]
on
SubmenuBar→"CUTTERADJ"window)
The unrequired portions of the uorine sheet are cut and fall down into
the scrap box of the bank feeder change cart.
Notice
Besuretocuttheunrequiredportionsoftheuorinesheetwithout
the tape being threaded through the cutters. Otherwise, the tape
cannot be cut normally.
4.3 Replacement of Fluorine Sheet and Urethane Clamp
1-52
0709-001
4.4 Procedure of Flat Ring Replacement
Time of Replacement
It is recommended that they should be replaced every 3 months (approx.).
Replacement Procedure
Procedure
(1) Zero the cutter.
Reference
Refer to "4.4 "CUTTER ADJ" Window" in "Chapter 4 (Vol. 2)" for
the zeroing operation of the cutter.
(2) Move down the feeder base and detach the bank feeder change
cart.
(3) Turn off the power to the machine.
(4) Open the cover.
(5) Detach the transparent cover (origin and motor sides) and the
tape guide.
Notice
(a) Carefully detach or attach the tape guide to avoid the
Y-axis linear scale being scratched.
(b) When the cutter is not located at its origin, the tape guide
cannotbedetachedbecausetheuorinesheetiscaught
by the tape clamp.
Tape Guide
Transparent Cover
(Motor Side)
Transparent
Cover
(Origin Side)
Fig. 4A51
4.4 Procedure of Flat Ring Replacement
