HC1/HC2 控制板回流炉设置向导
型号：
客户名称：
CO＃
序列号：
软件版本：
日期：
Page 1
Oven Model: _________________________ (select from 4 to 17 zone model)
Oven Direction:
Left to Right
Right to Left
Use Custom Background
Controller Type
HC1
HC2
HC2 IP Address:
192 . 168 . 10 . 250
Temperature:
Deg C
or
Deg F
Speed: /sec or /min
Cooldown SP: _95_Deg
Length:
Cm
or
inch
HC2 Global High Process: _450_Deg
HC2 Alerts on Comm. Loss
Startup Parameters:
Maximum Output before next Group Start : 80 %
Power up Delay Time : 5 sec.
Maximum Heat Zones in Startup Group : 4
T/C Short Detection:
Minimum Heater Temp Rise : 5
O
C or 9
O
F (1
O
C for IR-panels)
Rise Check Period : 60 sec
Warning on rise rate
Power Draw Warning : 100 %
Oven Label Text:
OVEN
Opaque Background
Power Failure Detection Time: 15 sec
Barcode:
Launch the following program:
Start Barcode Reader Set BC Program Path
Audible Alarm on Barcode Error
File Path: C:\ECD\OvenCpCpk\OvenCpCpk.exe
SECS/GEM Interface
Default Language: English
File Path: C:\HellerSecsgem\HellerSecsgem.exe
KIC-LDO _______ Sec
