Page 3
Blower Control Setup:
RPM Warning Level: _______, _______, ________ Type: ___________________
% or RPM Single or L-M-H Inte. Exh. Standby Mode Low/Min Medium High Labels
Group A:
____
_____ _____ __________
Group B:
____
_____ _____ __________
Group C:
____
_____ _____ __________
Group D:
____
_____ _____ __________
Group E:
____
_____ _____ __________
Blower Initial 100% On Time: __15__ Sec.
Blowers at 100% during recipe startup
Upstream Signal : ___________________________
Select Blower RPM Setup file: _________________________
(Warning for RPM setup, make sure that blower RPM graph(*.csv) file has correct data according to control hardware and blower
used.)
Blower Failure:
Blower RPM Port Setup…
Alarm 30 Sec.
Warning 15 Sec.
Audible Warning
Enable Terminal Read….
Select Analog (Thermocouple) Input:
Select TPO Output:
Visible Flux 1 heater
Flux 1 heater
________________________
____________________
Visible Flux 2 heater
Flux 2 heater
________________________
____________________
Visible Flux 3 heater
Flux 3 heater
________________________
____________________
Top 13:
________________________
____________________
Bottom 13:
________________________
____________________
Top 14:
________________________
____________________
Bottom 14:
________________________
____________________
Blower RPM Port Setting
PC Communication Settings
Blower RPM Port Settings
COM Port:
__________
Number of Boards:
_____
Bits per second:
4800
Sampling rate (Sec):
5
Data bits:
8
Alarm Relay RPM Value:
1000
Parity:
None
Max Blowers:
_____
Stop bits:
1
Terminal Read Setting
Tag Label: ___________
COM Port: ___________
Bits per second: _______
Data Bits: ____________
Parity:_______________
Stop bits: ____________
59
Page 4
Movable Rails and Rail Configuration: (Computer controlled rails)
1
st
Computer controlled Rail Width
Control Type: Automatic
3
rd
Computer controlled Rail Width
Control Type: Automatic
Coast Offset:____cm
Home IN
Coast Offset:____cm
Home IN
Backup Dist:____cm
Hunt as Home IN
Backup Dist:____cm
Hunt as Home IN
Home Dist:_____cm
Travel Dist:_____Min ______Max
Pulse per cm: 1576
Tolerance +_____ - _____ cm
Maximum Retry: _____ Lane: _________
Home Dist:_____cm
Travel Dist:_____Min ______Max
Pulse per cm: 1576
Tolerance +_____ - _____ cm
Maximum Retry: _____ Lane: _________
2
nd
Computer controlled Rail Width
Control Type: Automatic
4
th
Computer controlled Rail Width
Control Type: Automatic
Coast Offset:____cm
Home IN
Coast Offset:____cm
Home IN
Backup Dist:____cm
Hunt as Home IN
Backup Dist:____cm
Hunt as Home IN
Home Dist:_____cm
Travel Dist:_____Min ______Max
Pulse per cm: 1576
Tolerance +_____ - _____ cm
Maximum Retry: _____ Lane: _________
Home Dist:_____cm
Travel Dist:_____Min ______Max
Pulse per cm: 1576
Tolerance +_____ - _____ cm
Maximum Retry: _____ Lane: _________
Manual (Hardware) Rail Controls
Rail startup group: ______
Rail exercise feature
2
nd
Cbs Exercises w/Rail: _____________
(Set rail drive motor voltage for EXL/MK3.5 Model between 48V to 53V, for SX Model set between 28V
to 33V)
(For single edge hold select, 1st Computer Controlled Rail Width,
For dual edge hold select, 1st and 2nd Computer Controlled Rail Width,
For single edge hold w/ CBS select, 1st Rail Width for CBS and 2
nd
Rail Width for Edge Hold)
Page 5
Conveyor Belt Options
Slow Belt Display & Warning
Bands
Show actual Belt PV in Deadband
Audible Alarm on Belt Warning
Auto Acknowledge Warning on Ok
Audible Alarm on Low Exhaust
Warning
Audible alarm on DansensoWarning
Disable New Job Output
Disable Heat Zone DeviationAlarms
Disable Auto AcknowledgeWarnings
Run Multimedia file on Alarm
Run Multimedia file on Warning
Monitoring Temperature HC2
Alarm Scanner
Output: _____________________
Backup / Duplicate Belt Controller
Belt Selection Relay: ______________
Belt Selection Output: _____________
Alarming & Cooldown Delays
High Process Delay: ____ sec
Delayed Cooldown, Delay Time: ____ min
Switch Delay: _____ Sec.
Audible Alarm when switch to:
Motor-B
Input-B
Create Channel Groupings:
Group1
Group2
Group3
Group4
60
Page 6
Belt Speed Control
BELT ONE
BELT TWO
Closed Loop
Closed Loop
Input range high : ______ /min
Input range high : ______ /min
Input range low : 0 cm/min or in/min
Input range low : 0 cm/min or in/min
Max Frequency : ______ Hz
Max Frequency : ______ Hz
Warning Delay Time: _____ sec
Warning Delay Time: _____ sec
Deadband Dev Time: _____ sec
Deadband Dev Time: _____ sec
Open Loop (for 1088)
Maximum output : 100% = 100 cm/min
Minimum output : 0% = 0 cm/min
Switch Range >= _____cm/min or in/min
Switch Output: ___________________
Audible Board
Warning
Smema Lane #3
Predefined
board length:
Audible Board
Warning
Smema Lane #4
Board processed
Animation Lane #3
Board processed
Animation Lane #4
Board in Oven
Animation Lane #1
______ cm
Board in Oven
Animation Lane #2
Board Drop Warning – Timed
Exit Board Stop Warning
Sensor distance : cm or inch
SMEMA 9851 new Board
delay (Spacing):
_______ cm
Board drop alarm – Timed
Exit Board Stop Warning
Sensor distance: cm or inch
Interface type : _______________
Oven Cure SMEMA
Belt Stop Delay: ____ Sec
Interface type : _________________
Board Cutout(Spacing) Entrance : cm
Board Cutout(Spacing) Entrance : cm
Board Cutout(Spacing) Exit : cm
Entrance Board
Jam/Stop Warning
Board Cutout(Spacing) Exit : cm
Board Stop Time : sec
Board Stop Time : sec
Board Drop Tolerance + : cm
Board Exit Tolerance - : cm
Disable board length from board drop calculation
Board Sensor Delay Output
_________________________
On After :_____cm (Board length) + Duration :_____cm
New Recipe Delay : cm
Lot tracking
Enable/Disable lot tracking button
Red Light on board drop/stop
Delayed-Timed Output
Animation Bottom to Top
Board Warning Digital Output
Digital output on board count
Max boards per lane using SMEMA ____
Board In/Out (Sensor trigger
only, no animation)
(Must enter a sensor distance value for all ovens with board count or board drop option)
