SIPLACE

Placement Systems

Z-Axis Miniature Rolling Bearing Replacement

C&P (M 8000, M 10000, DLM1)

. Seite 2

SIPLACE

Placement Systems

Comply with the applicable safety and accident prevention

instructions

Adhere to the safety instructions in the USER Manual

Safety Instructions

. Seite 3

SIPLACE

Placement Systems

¾ race way gap gauge (00335346-01)¾ gauge for raceway (00333625-01)

¾ gauge for z-axis upper stop:

Attention: z-axis gauge for DLM head

see TI 10C06014,

don’t mix it up with the gauge for adjusting the

zero point correction star axis

order number:

00326164-01)

Attention: z-axis gauge for C&P M 8000 / M 10000

Tools and Measuring Equipment

Tools
