© Siemens AG . . Änderungen vorbehalten SIPLACE Placement Systems glass components Calculation: grid in gl ass comp onent (hol e) in respect to grid s on glass plate (xy and angle) grids on glass plate 1 4 3 2 Offset Cal…
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
ceramic component
Calculation: offset of component center in respect to the grids on the glass plate
(only xy values)
grids on glass plate 1-4
1xy
2xy
3xy
4xy
Offset Calculation
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
glass components
Calculation: grid in glass component (hole) in respect to grids on glass plate (xy and angle)
grids on glass plate
1
4
3
2
Offset Calculation
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
Fine Calibration Results
Graph below: result after Fine Calibration S27HM. All components are shifted in X-
direction
Offset
