© Siemens AG . . Änderungen vorbehalten SIPLACE Placement Systems single value diagram final state: x-offset 0 20 40 60 80 100 number of placements -300 -250 -200 -150 -100 -50 0 50 100 150 200 250 x-Versat z [µm] x-dire…
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
x-offset single values: final state
0 90 180 270 0 90 180 270 0 90 180 270
color atlas
Example 2: Offset at Placement Angle
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
single value diagram final state: x-offset
0 20 40 60 80 100
number of
placements
-300
-250
-200
-150
-100
-50
0
50
100
150
200
250
x-Versatz [µm]
x-direction
irregularity???
0
90
180
270
Graph
Example 2: Offset at Placement Angle
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
With performing a trend analysis we can recognize mapping errors,
e.g. as higher the y-coordinate, as higher the deviation
which trend is visible?
¾ offset increases with rising x-values (depending on the placement coordinate)
therefore required specification not achieved (C
m
-value).
Trend Analysis
Attention:
nevertheless, the average value can be in tolerance and a correction is normally not
possible by changing any software values.
