Mapping Plates (Glass)
. Seite 4
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
Mapping Plates (Glass)
Attention:
For application on double transport, please turn Version 3 for 90 degree;
The arrows on the mapping plate indicate the direction.
Calibration of Mapping Plates
Mapping plates must be recalibrated every four years.
The date for the next recalibration is on the calibration certificate.
Please contact the SCC in Munich for detailed information.
. Seite 5
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
Mapping Plates (Alu)
