© Siemens AG . . Änderungen vorbehalten SIPLACE Placement Systems temperature environment (necessary) comment table with corrected da ta (corrected machine offsets can b e written down he re as comment Start Measurement …
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
Inspection plan: various placement heads
max. number of placement heads (chip shooter)
head number which starts placement
CM Controller – Measuring Project
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
temperature environment
(necessary)
comment
table with corrected data
(corrected machine offsets can be
written down here as comment
Start Measurement
CM Controller – Measuring Project
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
number of measurement, e.g result
of measurement number two from
several measures
specification limits
average value
machine capability parameter
(Cm, Cmk)
Evaluation
CM Controller – Measuring Project
