. Seite 4 © Siemens AG . . Änderungen vorbehalten SIPLACE Placement Systems Pieces Type Dime nsi on Location 4 DI N 84 M2x4mm Z-bea ri ng 3 DIN 912 M 3x5mm Bearing race 2 D IN 91 6 M 1 , 6x2 , 5mm F orced-air tube 2 DIN …

. Seite 3

SIPLACE

Placement Systems

¾ race way gap gauge (00335346-01)¾ gauge for raceway (00333625-01)

¾ gauge for z-axis upper stop:

Attention: z-axis gauge for DLM head

see TI 10C06014,

don’t mix it up with the gauge for adjusting the

zero point correction star axis

order number:

00326164-01)

Attention: z-axis gauge for C&P M 8000 / M 10000

Tools and Measuring Equipment

Tools

. Seite 4

SIPLACE

Placement Systems

Pieces Type Dimension Location

4 DIN 84 M2x4mm Z-bearing

3 DIN 912 M3x5mm Bearing race

2 DIN 916 M1

6x2

5mm Forced-air tube

2 DIN 912 M2x4mm Driver plate

3 DIN 912 M3x8mm Star

4 DIN 912 M4x16mm Front part head

1 DIN 912 M5x16mm Star motor

2 DIN 912 M3x10mm Valve drive

ensure the following spare parts are available:

¾ raceway (00319327-06)

¾ miniature rolling bearing (00320165-02)

¾ spare screws

DIN 84: slotted head screws

DIN 912: hexagon socket screws

DIN 916: grub screw

Spare Parts

. Seite 5

SIPLACE

Placement Systems

¾ fix the revolver head front part at the head stand,or alternatively,

place the front part into the protective cover (delivered with a new head)

if available.

¾ remove the sleeves and keep them in the container provided for this

purpose

¾ remove the vacuum distributor.

¾ remove the 3 hexagon socket screws M3x8 (allen wrench 2.5 mm) star.

¾ lift the star carefully until you feel slight resistance.

Pull the 3 segments, located below the screw holes outwards.

ATTENTION: when reassembling, fasten the star to motor shaft in the

same position as it was before disassembly. To do this, mark a

screw positions on the star and on the shaft.

Disassembly Z-Axis
