. Seite 7 © Siemens AG . . Änderungen vorbehalten SIPLACE Placement Systems Graphical Result PCB Mapping The mapping result can be displayed with SW MAPP32.exe (C:\SR\Tools). Mapp_11 show the result for gantry 1 at trans…
. Seite 6
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
Preparation for Mapping
Menue ‘Mapping’
executes only the PCB mapping.
Menue ‘Mapping and Heads’
executes only the BCB mapping and RV mapping of C&P head, as also the IC-Mapping of TWIN-
head.
Calibration tools will be used in serial modus with one mapping plate or in parallel modus with two
or more Mapping plates.
min. 1 nozzle 956 is required at the C&P-head;
nozzle 517 is required on TWIN head
with starting PCB mapping, any corner at the mapping plate can be taught as reference corner.
from this corner as reference, a cross-type-fiducial is measured and in conjunction with another
fiducial on the other side, the angle offset of the mapping-plate is measured.
. Seite 7
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
Graphical Result PCB Mapping
The mapping result can be
displayed with SW MAPP32.exe
(C:\SR\Tools).
Mapp_11 show the result for
gantry 1 at transport 1
The distance between 2 mapping
positions is 40 mm
The mapping position on right
bottom is the nearest to the machine
zero point
Attention: automatic scaling
. Seite 8
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
Mapp_11 show the result for
gantry 1 on transport 1.
The distance between 2
mapping positions is 40 mm
The mapping position on right
bottom is the nearest to the
machine zero point
Graphical Result RV Mapping
