© Siemens AG . . Änderungen vorbehalten SIPLACE Placement Systems numerical evaluation Trend Analysis
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
With performing a trend analysis we can recognize mapping errors,
e.g. as higher the y-coordinate, as higher the deviation
which trend is visible?
¾ offset increases with rising x-values (depending on the placement coordinate)
therefore required specification not achieved (C
m
-value).
Trend Analysis
Attention:
nevertheless, the average value can be in tolerance and a correction is normally not
possible by changing any software values.
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
numerical evaluation
Trend Analysis
© Siemens AG . . Änderungen vorbehalten
SIPLACE
Placement Systems
X-offset single values
X-offset single values placement 1
x-axis
transport direction
y-Achse
Trend Analysis
