MODEL TPM-200F/R 0207-001 Key No . P AR T No. P AR T NAME Q’ty REMARKS NOTE 231 P-5 40 1 630 064 6528 SWITCH,BUTTON 2 SPB010,01 1 782P--1 10-401 40 2 630 089 2703 HANDLE 1 782P--1 10-402 40 3 630 091 1855 NAME PLA TE,IND…

MODEL TPM-200F/R

0207-001

230

カバー部 COVER SECTION

Fig. P-5 電装部 Electrical Parts

Fig.P-5

TPM-200F/R

402

401

404

403

401

See Fig.K-1

Key No.1

401

MODEL TPM-200F/R

0207-001

Key No. PART No. PART NAME Q’ty REMARKS

NOTE

231

P-5

401 630 064 6528 SWITCH,BUTTON 2 SPB010,011 782P--110-401

402 630 089 2703 HANDLE 1 782P--110-402

403 630 091 1855 NAME PLATE,INDEX 1 782P--110-403

404 630 091 1862 NAME PLATE,INDEX 1 782P--110-404
