MEMO

MODEL TPM-200F/R

0207-001

Key No. PART No. PART NAME Q’ty REMARKS

NOTE

239

BF-1

1 630 107 2630 UNIT,DRIVER 4 APMD027,031,033,035, ASD24A-ASD

782BF-110-001

2 630 112 4834 CORD 1 XNC355-XNC1350,1357

782BF-110-002

3 630 112 4841 CORD 1 XCN356-XNC1351,1356

782BF-110-003

4 630 107 2647 UNIT,DRIVER 1 APMD029,ASD30D-ASD

782BF-110-004

5 630 112 4889 CORD 1 XNC290-XNC295 782BF-110-005

6 630 112 4896 CORD 1 XCN296-XNC1291,1296

782BF-110-006

7 630 112 4865 CORD 1 XNC315-XNC1310,1317

782BF-110-007

8 630 112 4872 CORD 1 XCN316-XNC1311,1316

782BF-110-008

9 630 112 4858 CORD 1 XCN336-XNC1331,1336

782BF-110-009

10 630 112 4933 CORD 1 XNC270-XNC275 782BF-110-010

11 630 112 4902 CORD 1 XCN276-XNC1271,1276

782BF-110-011

12 630 112 4919 CORD 1 782BF-110-012

61 411 043 5004 SCR PAN 4X8 18 782BF-110-061

62 411 008 1706 WASHER SPR 4 18 782BF-110-062

63 411 119 2104 WASHER V 4X9X0.8 18 782BF-110-063

64 411 087 0508 WASHER IN TW 4 8 782BF-110-064

MEMO

MODEL TPM-200F/R

0207-001

241

Fig. HH 基板搬送部 P.C.B. TRANSFER SECTION
