MODEL TPM-200F/R
0207-001
94
スキージヘッド部 SQUEEGEE HEAD SECTION
Fig. FA-4 ケーブル Cable
Fig.FA-4
TPM-200F/R
See Fig.FA-1
Key No.40
321
361
362
363
301
302
303
307
304
305
320
365
364
366
364
365
366
367
306
310
308
309
311
312
A
A
301-10
301-10
MODEL TPM-200F/R
0207-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
95
FA-4
301 630 107 1824 UNIT,I/O 1 N053,#VP-SDS-SHC+VLS-50KX2
782FA-110-301
301 -10 630 106 5496 SENSOR 2 B001,002
302 630 013 7606 ACCESSORY,P.C.B 4 782FA-110-302
303 630 013 7637 ACCESSORY,P.C.B 4 782FA-110-303
304 630 112 5596 CORD 1 XCNA53,B53-XNC1A53,XCNA06,B06
782FA-110-304
305 630 112 5572 CORD 1 XNC311- 782FA-110-305
306 630 112 5626 CORD 1 782FA-110-306
307 630 112 5589 CORD 1 XCN534-XCN531,532
782FA-110-307
308 630 112 5602 CORD 1 XNC060,061-XNC1060,1061
782FA-110-308
309 630 112 5619 CORD 1 XNC062,063-XNC1062,1063
782FA-110-309
310 630 112 5633 CORD 1 XNC311-XNC1311 782FA-110-310
311 630 112 5657 CORD 1 XNC1A53-XNC2A53 782FA-110-311
312 630 112 5664 CORD 1 XNC310-XNC1310,1317
782FA-110-312
320 630 106 4611 UNIT,I/O 1 N006,SAB10-TM16H43A
782FA-110-320
321 630 091 1718 ACCESSORY,WIRING 1 782FA-110-321
361 411 162 1604 SCR PAN 3X20 4 782FA-110-361
362 411 086 4408 WASHER SPR 3 4 782FA-110-362
363 411 119 1909 WASHER V 3X7X0.5 4 782FA-110-363
364 411 043 5004 SCR PAN 4X8 5 782FA-110-364
365 411 008 1706 WASHER SPR 4 5 782FA-110-365
366 411 119 2104 WASHER V 4X9X0.8 5 782FA-110-366
367 411 087 0508 WASHER IN TW 4 3 782FA-110-367
