9. Maintenance
9.1 Periodic Maintenance
9.1.1 Precautionary Items
This section describes how to perform lubrication, inspections, and
cleaning work to keep the machine in good working condition. It is
recommended that the maintenance work be performed periodi-
cally.
• Do not air-blow.
If dirt and dust are dispersed, they adhere to various sensors,
ball screw, linear guide, etc., causing the machine break down.
• If the V. bend detection unit is operated with dirt and dust accu-
mulated, it will result in incorrect recognition.
9.1.2 Preparation for Maintenance
Preparation for Cleaning
Prepare the cleaning tools.
• Rag
Use a clean rag (cotton, etc.) which is as less waste thread as
possible.
0301-001
9. Maintenance
• Only qualified personnel should perform the
maintenance work carefully, following the
specified instructions.
WARNING
• Before performing maintenance work, turn off
the power and air source and lock the power
breaker using the padlock.
• Designate a person who can have charge of
the padlock key.
Refer to the Instruction Manual of the Main
Machine for details.
WARNING
32 Tg0742-PM-SO
9.1.4 Weekly Maintenance
9.1 Periodic Maintenance
0301-001
9.1.3 Daily Maintenance
Maintenance Spots
Description
Fig. No.
Required
Items
Check
V. Bend Detection Unit
13
Checking and
Cleaning
Fig. 13 V. Bend Detection Unit
Sensor Head Top
Every Day Checking and Cleaning
• Check visually that no foreign mat-
ter has accumulated when the op-
eration is started.
• If any foreign matter has accumu-
lated, remove it by hand.
Note: Do not air-blow.
Sensor Head Top
Every Week Cleaning
• Wipe off dirt and dust using a clean
rag.
Note: Do not air-blow.
Block Name Detailed Name
Sensor Head Top
Rag. etc.
Maintenance Spots
Fig. No.
Required
Items
Check
V. Bend Detection Unit
13
Cleaning
Block Name Detailed Name
Rag
The operator has to enter the machine in this work.
Before performing maintenance work, turn off the
power switch of the machine and the air source and
lock the power breaker using the padlock.
CAUTION
Sensor Head Top
Description
33 Tg0742-PM-SO0301-001
10. Component Recog. Test
Fig. 14 "Component Recog. Test" Window
10. Component Recog. Test
10.1 "Component Recog. Test" Tab
• Window Layout
When the [Component Recog. Test] button is pressed on the "Com-
ponent Recog. Test" tab sheet, the following "Component Recog.
Test" operation window appears.
Before V. bend testing, the component library data need to be input in
the test ID and the component pick-up and component recognition be
tested.
*1
