67 Tg0742-PM-SO 0307-002 13.1 IP Address Setting Procedure (10) Select the [DNS] tab and set the Host Name. Enter the name same as the computer name which will be set later . (1 1) “WINS Address” T ab The setting of the …

66 Tg0742-PM-SO0307-002

Fig. 39 IP Address Setting

13.1 IP Address Setting Procedure

(9) Set the IP Address and Subnet Mask.

Enter the IP Address using the keyboard.

• If the initial value has already been entered, change it.

Set the Subnet Mask.

• If the initial value has already been entered, change it.

• Enter the Subnet Mask parameters on the value (character

string).

(a) If the IP Address already has the serial number of TIM-

X100’s IP Address then it is not necessary to alter the

initial value of 255.255.255.0.

(b)

The Default Gateway setting is not required. (If it is

needed by the user then set the IP address for

Default Gateway).

67 Tg0742-PM-SO0307-002

13.1 IP Address Setting Procedure

(10) Select the [DNS] tab and set the Host Name.

Enter the name same as the computer name which will be set

later.

(11) “WINS Address” Tab

The setting of the WINS Address is not normally required.

However, if it is needed by the user then set it.

(12) When the setting is completed :

Press the [OK] button and escape from the TCP / IP Properties

window.

If the computer asks whether the machine should be restarted

or not then, later, restart the machine.

Fig. 40 Host Name Setting

68 Tg0742-PM-SO0307-002

(13) Return to the Network Setting window and press the [Change]

button in the Recognition tab sheet.

Then set the computer name. Participation in the

domain is not normally required. If it is required by the

user, set the domain.

Any name is all right for the computer name (set the name as

the same as the computer name set in the DNS). Set the

option button in the WORKGROUP and set the

WORKGROUP.

(If the WORKGROUP name is specified or participation in the

domain is needed by the user, follow the user’s instructions.)

(14)

Press the [OK] button.

(15) Restart the machine and if it starts up normally then the

setting has been completed.

13.1 IP Address Setting Procedure

Fig. 42 WORKGROUP SettingFig. 41 Computer Name Setting
