Meter Module Platform i i - - p p u u l l s s e e M M 8 8 Service Manual 900752#00
Meter Module Platform
i
i
-
-
p
p
u
u
l
l
s
s
e
e
M
M
8
8
Service Manual
900752#00
i-PULSE Co., Ltd.
1-9-3 Shinmiyakoda, Kita-Ku, Hamamatsu,
Shizuoka, 431-2103 Japan
TEL: 053-484-1875
FAX: 053-484-1870
URL: http://www.ipulse.co.jp
All rights received, No part of document may be reproduced or transmitted in any from or by any
means, electronic or mechanical, for any purpose, without the express permission of i-PULSE Co,. Ltd.
1
About This Manual
Thank you for purchasing the i-pulse mounter.
This manual functions as maintenance guide. Please be sure to read this manual before servicing the
mounter.
After reading this manual, keep it handy so that it will be available at any time.
Features:
z This manual consists of five sections: Installation, Periodical Checks, Mechanical Section, Electrical
Section and Materials.
z Index at the end of the manual makes topic finding quick and easy.
Style Conventions:
z Action: Shows steps to perform a certain task.
z Example: Shows a representative example.
z Note: Shows an important point that calls for attention.
z
)
Shows the reference page or manual.
[ ]: Tab titles and sub-titles in the MMI windows are enclosed in these brackets.
< >: Buttons in the MMI windows are enclosed in these brackets.
“ “: User entries for the MMI windows are enclosed in double quotations.
: Controls on the machine control panel are boxed.
z An especially important point is highlighted as shown below:
Example:
The mounter may not function properly when grease sticks to the sensors and
the cameras.
