4 Electrical Section

4-8

Address Bit No. Signal Name Address Bit No. Signal Name

0009h 0 Teach Side Illumi. Lighting Time Bit 8

0012h 0 Beam 1 Side Illumi. PWM Bit 0

1 Teach Side Illumi. Lighting Time Bit 9

1 Beam 1 Side Illumi. PWM Bit 1

2 Teach Side Illumi. Lighting Time Bit 10

2 Beam 1 Side Illumi. PWM Bit 2

3 Teach Side Illumi. Lighting Time Bit 11

3 Beam 1 Side Illumi. PWM Bit 3

4 Teach Side Illumi. Lighting Time Bit 12

4 Beam 1 Side Illumi. PWM Bit 4

5 Teach Side Illumi. Lighting Time Bit 13

5 Beam 1 Side Illumi. PWM Bit 5

6 Teach Side Illumi. Lighting Time Bit 14

6 Beam 1 Side Illumi. PWM Bit 6

7 Teach Side Illumi. Lighting Time Bit 15

7 Beam 1 Side Illumi. PWM Bit 7

000Ah 0 Teach Side Illumi. PWN Bit 0

0014h 0 Beam 1 Diffuse Illumi. Lighting Time Bit 0

1 Teach Side Illumi. PWN Bit 1

1 Beam 1 Diffuse Illumi. Lighting Time Bit 1

2 Teach Side Illumi. PWN Bit 2

2 Beam 1 Diffuse Illumi. Lighting Time Bit 2

3 Teach Side Illumi. PWN Bit 3

3 Beam 1 Diffuse Illumi. Lighting Time Bit 3

4 Teach Side Illumi. PWN Bit 4

4 Beam 1 Diffuse Illumi. Lighting Time Bit 4

5 Teach Side Illumi. PWN Bit 5

5 Beam 1 Diffuse Illumi. Lighting Time Bit 5

6 Teach Side Illumi. PWN Bit 6

6 Beam 1 Diffuse Illumi. Lighting Time Bit 6

7 Teach Side Illumi. PWN Bit 7

7 Beam 1 Diffuse Illumi. Lighting Time Bit 7

000Ch 0 Teach Coaxial Illumi. Lighting Time Bit 0 0015h 0 Beam 1 Diffuse Illumi. Lighting Time Bit 8

1 Teach Coaxial Illumi. Lighting Time Bit 1 1 Beam 1 Diffuse Illumi. Lighting Time Bit 9

2 Teach Coaxial Illumi. Lighting Time Bit 2 2 Beam 1 Diffuse Illumi. Lighting Time Bit 10

3 Teach Coaxial Illumi. Lighting Time Bit 3 3 Beam 1 Diffuse Illumi. Lighting Time Bit 11

4 Teach Coaxial Illumi. Lighting Time Bit 4 4 Beam 1 Diffuse Illumi. Lighting Time Bit 12

5 Teach Coaxial Illumi. Lighting Time Bit 5 5 Beam 1 Diffuse Illumi. Lighting Time Bit 13

6 Teach Coaxial Illumi. Lighting Time Bit 6 6 Beam 1 Diffuse Illumi. Lighting Time Bit 14

7 Teach Coaxial Illumi. Lighting Time Bit 7 7 Beam 1 Diffuse Illumi. Lighting Time Bit 15

000Dh 0 Teach Coaxial Illumi. Lighting Time Bit 8 0016h 0 Beam 1 Diffuse Illumination PWN Bit 0

1 Teach Coaxial Illumi. Lighting Time Bit 9 1 Beam 1 Diffuse Illumination PWN Bit 1

2 Teach Coaxial Illumi. Lighting Time Bit 10 2 Beam 1 Diffuse Illumination PWN Bit 2

3 Teach Coaxial Illumi. Lighting Time Bit 11 3 Beam 1 Diffuse Illumination PWN Bit 3

4 Teach Coaxial Illumi. Lighting Time Bit 12 4 Beam 1 Diffuse Illumination PWN Bit 4

5 Teach Coaxial Illumi. Lighting Time Bit 13 5 Beam 1 Diffuse Illumination PWN Bit 5

6 Teach Coaxial Illumi. Lighting Time Bit 14 6 Beam 1 Diffuse Illumination PWN Bit 6

7 Teach Coaxial Illumi. Lighting Time Bit 15 7 Beam 1 Diffuse Illumination PWN Bit 7

000Eh 0 Teach Coaxial Illumination PWM Bit 0 0018h 0 Beam 1 Coaxial Illumi. Lighting Time Bit 0

1 Teach Coaxial Illumination PWM Bit 1 1 Beam 1 Coaxial Illumi. Lighting Time Bit 1

2 Teach Coaxial Illumination PWM Bit 2 2 Beam 1 Coaxial Illumi. Lighting Time Bit 2

3 Teach Coaxial Illumination PWM Bit 3 3 Beam 1 Coaxial Illumi. Lighting Time Bit 3

4 Teach Coaxial Illumination PWM Bit 4 4 Beam 1 Coaxial Illumi. Lighting Time Bit 4

5 Teach Coaxial Illumination PWM Bit 5 5 Beam 1 Coaxial Illumi. Lighting Time Bit 5

6 Teach Coaxial Illumination PWM Bit 6 6 Beam 1 Coaxial Illumi. Lighting Time Bit 6

7 Teach Coaxial Illumination PWM Bit 7 7 Beam 1 Coaxial Illumi. Lighting Time Bit 7

0010h 0 Beam 1 Side Illumi. Lighting Time Bit 0 0019h 0 Beam 1 Coaxial Illumi. Lighting Time Bit 8

1 Beam 1 Side Illumi. Lighting Time Bit 1 1 Beam 1 Coaxial Illumi. Lighting Time Bit 9

2 Beam 1 Side Illumi. Lighting Time Bit 2 2 Beam 1 Coaxial Illumi. Lighting Time Bit 10

3 Beam 1 Side Illumi. Lighting Time Bit 3 3 Beam 1 Coaxial Illumi. Lighting Time Bit 11

4 Beam 1 Side Illumi. Lighting Time Bit 4 4 Beam 1 Coaxial Illumi. Lighting Time Bit 12

5 Beam 1 Side Illumi. Lighting Time Bit 5 5 Beam 1 Coaxial Illumi. Lighting Time Bit 13

6 Beam 1 Side Illumi. Lighting Time Bit 6 6 Beam 1 Coaxial Illumi. Lighting Time Bit 14

7 Beam 1 Side Illumi. Lighting Time Bit 7 7 Beam 1 Coaxial Illumi. Lighting Time Bit 15

0011h 0 Beam 1 Side Illumi. Lighting Time Bit 8 001Ah 0 Beam 1 Coaxial Illumination PWM Bit 0

1 Beam 1 Side Illumi. Lighting Time Bit 9 1 Beam 1 Coaxial Illumination PWM Bit 1

2 Beam 1 Side Illumi. Lighting Time Bit 10 2 Beam 1 Coaxial Illumination PWM Bit 2

3 Beam 1 Side Illumi. Lighting Time Bit 11 3 Beam 1 Coaxial Illumination PWM Bit 3

4 Beam 1 Side Illumi. Lighting Time Bit 12 4 Beam 1 Coaxial Illumination PWM Bit 4

5 Beam 1 Side Illumi. Lighting Time Bit 13 5 Beam 1 Coaxial Illumination PWM Bit 5

6 Beam 1 Side Illumi. Lighting Time Bit 14 6 Beam 1 Coaxial Illumination PWM Bit 6

7 Beam 1 Side Illumi. Lighting Time Bit 15 7 Beam 1 Coaxial Illumination PWM Bit 7

4 Electrical Section

4-9

Address Bit No. Signal Name Address Bit No. Signal Name

001Ch 0 Beam 2 Side Illumi. Lighting Time Bit 0 0022h 0 Beam 2 Diffuse Illumination PWN Bit 0

1 Beam 2 Side Illumi. Lighting Time Bit 1 1 Beam 2 Diffuse Illumination PWN Bit 1

2 Beam 2 Side Illumi. Lighting Time Bit 2 2 Beam 2 Diffuse Illumination PWN Bit 2

3 Beam 2 Side Illumi. Lighting Time Bit 3 3 Beam 2 Diffuse Illumination PWN Bit 3

4 Beam 2 Side Illumi. Lighting Time Bit 4 4 Beam 2 Diffuse Illumination PWN Bit 4

5 Beam 2 Side Illumi. Lighting Time Bit 5 5 Beam 2 Diffuse Illumination PWN Bit 5

6 Beam 2 Side Illumi. Lighting Time Bit 6 6 Beam 2 Diffuse Illumination PWN Bit 6

7 Beam 2 Side Illumi. Lighting Time Bit 7 7 Beam 2 Diffuse Illumination PWN Bit 7

001Dh 0 Beam 2 Side Illumi. Lighting Time Bit 8 0024h 0 Beam 2 Coaxial Illumi. Lighting Time Bit 0

1 Beam 2 Side Illumi. Lighting Time Bit 9 1 Beam 2 Coaxial Illumi. Lighting Time Bit 1

2 Beam 2 Side Illumi. Lighting Time Bit 10 2 Beam 2 Coaxial Illumi. Lighting Time Bit 2

3 Beam 2 Side Illumi. Lighting Time Bit 11 3 Beam 2 Coaxial Illumi. Lighting Time Bit 3

4 Beam 2 Side Illumi. Lighting Time Bit 12 4 Beam 2 Coaxial Illumi. Lighting Time Bit 4

5 Beam 2 Side Illumi. Lighting Time Bit 13 5 Beam 2 Coaxial Illumi. Lighting Time Bit 5

6 Beam 2 Side Illumi. Lighting Time Bit 14 6 Beam 2 Coaxial Illumi. Lighting Time Bit 6

7 Beam 2 Side Illumi. Lighting Time Bit 15 7 Beam 2 Coaxial Illumi. Lighting Time Bit 7

001Eh 0 Beam 2 Side Illumination PWM Bit 0 0025h 0 Beam 2 Coaxial Illumi. Lighting Time Bit 8

1 Beam 2 Side Illumination PWM Bit 1 1 Beam 2 Coaxial Illumi. Lighting Time Bit 9

2 Beam 2 Side Illumination PWM Bit 2 2 Beam 2 Coaxial Illumi. Lighting Time Bit 10

3 Beam 2 Side Illumination PWM Bit 3 3 Beam 2 Coaxial Illumi. Lighting Time Bit 11

4 Beam 2 Side Illumination PWM Bit 4 4 Beam 2 Coaxial Illumi. Lighting Time Bit 12

5 Beam 2 Side Illumination PWM Bit 5 5 Beam 2 Coaxial Illumi. Lighting Time Bit 13

6 Beam 2 Side Illumination PWM Bit 6 6 Beam 2 Coaxial Illumi. Lighting Time Bit 14

7 Beam 2 Side Illumination PWM Bit 7 7 Beam 2 Coaxial Illumi. Lighting Time Bit 15

0020h 0 Beam 2 Diffuse Illumi. Lighting Time Bit 0 0026h 0 Beam 2 Coaxial Illumination PWM Bit 0

1 Beam 2 Diffuse Illumi. Lighting Time Bit 1 1 Beam 2 Coaxial Illumination PWM Bit 1

2 Beam 2 Diffuse Illumi. Lighting Time Bit 2 2 Beam 2 Coaxial Illumination PWM Bit 2

3 Beam 2 Diffuse Illumi. Lighting Time Bit 3 3 Beam 2 Coaxial Illumination PWM Bit 3

4 Beam 2 Diffuse Illumi. Lighting Time Bit 4 4 Beam 2 Coaxial Illumination PWM Bit 4

5 Beam 2 Diffuse Illumi. Lighting Time Bit 5 5 Beam 2 Coaxial Illumination PWM Bit 5

6 Beam 2 Diffuse Illumi. Lighting Time Bit 6 6 Beam 2 Coaxial Illumination PWM Bit 6

7 Beam 2 Diffuse Illumi. Lighting Time Bit 7 7 Beam 2 Coaxial Illumination PWM Bit 7

0021h 0 Beam 2 Diffuse Illumi. Lighting Time Bit 8 0027h 0

1 Beam 2 Diffuse Illumi. Lighting Time Bit 9 1

2 Beam 2 Diffuse Illumi. Lighting Time Bit 10 2

3 Beam 2 Diffuse Illumi. Lighting Time Bit 11 3

4 Beam 2 Diffuse Illumi. Lighting Time Bit 12 4

5 Beam 2 Diffuse Illumi. Lighting Time Bit 13 5

6 Beam 2 Diffuse Illumi. Lighting Time Bit 14 6

7 Beam 2 Diffuse Illumi. Lighting Time Bit 15 7

4 Electrical Section

4-10

■ Device 3

Safety Circuit (XiO,M18) is controlled.

Address Bit No. Signal Name Address Bit No. Signal Name

0000h 0 Signal Tower (1) Lighting 0004h 0 Feeder Bank Board Control (F) ON

1 Signal Tower (2) Lighting 1 Feeder Bank Board Control (R) ON

2 Signal Tower (3) Lighting 2 Feeder Bank Power Supply (F) ON

3 Signal Tower (4) Lighting 3 Feeder bank Power Supply (R) ON

4 Signal Tower (5) Lighting 4

5 Warning Sound 5

6 Hazard Sound 6

7 UPS (1) Output 7

0001h 0 READY Output 0005h 0 Docking Station (F) Clamp ON

1 Lower During Operation 1 Docking Station (F) Clamp Off

2 Board Available Output 2 Docking Station (F) Positioning ON

3 Upper During Operation 3 Docking Station (F) Positioning Off

4 Internal Illumination ON 4 Docking Station (R) Clamp ON

5 5 Docking Station (R) Clamp Off

6 6 Docking Station (R) Positioning ON

7 7 Docking Station (R) Positioning Off

0002h 0 0006h 0 Front LCD Horizontal

1 Safety Relay Reset 1 Front LCD Vertical

2 Front Cover Lock 2

3 Rear Cover Lock 3

4 CTF Servo Power Supply (F) 4 Rear LCD Horizontal

5 CTF Servo Power Supply (R) 5 Rear LCD Vertical

6 6

7 7

0003h 0 Servo ON Permission 1 0007h 0

1 Servo ON Permission 2 1

2 2

3 3

4 4

5 5

6 6

7 7

■ Device 5

Lighting LED of the front operation switches.

Address Bit No. Signal Name Address Bit No. Signal Name

0000h 0 RESET SW(F) 0001h 0 DOCKING SW(F)

1 START SW(F) 1 OPTION SW(F)

2 STOP SW(F) 2

3 CLEAR SW(F) 3

4 SAFTY SW(F) 4

5 READY SW(F) 5

6 ACTIVE SW(F) 6

7 DISPLAY SW(F) 7
