4 Electrical Section
4-11
■ Device 7
Lighting LEDs of Rear Operation Switches.
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 RESET SW(R) 0002h 0 DOCKING SW(R)
1 START SW(R) 1 OPTION SW(R)
2 STOP SW(R) 2
3 CLEAR SW(R) 3
4 SAFTY SW(R) 4
5 READY SW(R) 5
6 ACTIVE SW(R) 6
7 DISPLAY SW(R) 7
■ Device 9
Activate each units of the conveyor.
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 0002h 0
1 Board Stopper (Option) 1
2 2
3 Conveyor Sensor Power 3 Conveyor 1 Rotation
4 ANC A Open 4 Conveyor 2 Rotation
5 5 Conveyor 3 Rotation
6 6
7 Entrance Shutter Close 7
0001h 0 0006h 0 Conveyor 1 Speed Data Bit 0
1 1 Conveyor 1 Speed Data Bit 1
2 2 Conveyor 1 Speed Data Bit 2
3 3 Conveyor 1 Speed Data Bit 3
4 4 Conveyor 1 Speed Data Bit 4
5 5 Conveyor 1 Speed Data Bit 5
6 Board Stopper 6 Conveyor 1 Speed Data Bit 6
7 7 Conveyor 1 Speed Data Bit 7
0002h 0 Main Clamp Up 0008h 0 Conveyor 2 Speed Data Bit 0
1 Main Clamp Down 1 Conveyor 2 Speed Data Bit 1
2 2 Conveyor 2 Speed Data Bit 2
3 Conveyor Sensor Power (Option) 3 Conveyor 2 Speed Data Bit 3
4 4 Conveyor 2 Speed Data Bit 4
5 5 Conveyor 2 Speed Data Bit 5
6 6 Conveyor 2 Speed Data Bit 6
7 7 Conveyor 2 Speed Data Bit 7
0003h 0 000Ah 0 Conveyor 3 Speed Data Bit 0
1 1 Conveyor 3 Speed Data Bit 1
2 2 Conveyor 3 Speed Data Bit 2
3 AMF Vacuum Stage 3 Conveyor 3 Speed Data Bit 3
4 4 Conveyor 3 Speed Data Bit 4
5 5 Conveyor 3 Speed Data Bit 5
6 6 Conveyor 3 Speed Data Bit 6
7 7 Conveyor 3 Speed Data Bit 7
0004h 0 Conveyor 1 Rotation 0
1 Conveyor 2 Rotation 1
2 Conveyor 3 Rotation 2
3 3
4 4
5 Conveyor 1 Alarm Reset 5
6 Conveyor 2 Alarm Reset 6
7 Conveyor 3 Alarm Reset 7
4 Electrical Section
4-12
■ Device 11
Safety Operations (Front Side)
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Cover Switch Lock (F) 0001h 0
1 Shutter Open (F) 1
2 Setup SW (F) 2
3 Camera Illumination ON (F) 3
4 4
5 5
6 6
7 7
■ Device 13
Safety Operations (Rear Side)
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Cover Switch Lock (R) 0001h 0
1 Shutter Open (R) 1
2 Setup SW (R) 2
3 Setup SW (R) 3
4 Camera Illumination ON (R) 4
5 5
6 6
7 7
4 Electrical Section
4-13
DI MAP
■ Device 2
Vacuum Pressure Monitor
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Device No. Bit 0 0008h 0 Vacuum Head A4 Bit 0
1 Device No. Bit 1 1 Vacuum Head A4 Bit 1
2 Device No. Bit 2 2 Vacuum Head A4 Bit 2
3 Device No. Bit 3 3 Vacuum Head A4 Bit 3
4 Device Added Information Bit 0 4 Vacuum Head A4 Bit 4
5 Device Added Information Bit 1 5 Vacuum Head A4 Bit 5
6 Device Added Information Bit 2 6 Vacuum Head A4 Bit 6
7 Output Register Value Bit 0 7 Vacuum Head A4 Bit 7
0003h 0 Output Register Value Bit 1 000Ah 0 Vacuum Head A5 Bit 0
1 Output Register Value Bit 2 1 Vacuum Head A5 Bit 1
2 Output Register Value Bit 3 2 Vacuum Head A5 Bit 2
3 Output Register Value Bit 4 3 Vacuum Head A5 Bit 3
4 Input Register Value Bit 0 4 Vacuum Head A5 Bit 4
5 Input Register Value Bit 1 5 Vacuum Head A5 Bit 5
6 Input Register Value Bit 2 6 Vacuum Head A5 Bit 6
7 Input Register Value Bit 3 7 Vacuum Head A5 Bit 7
0002h 0 Vacuum Head A1 Bit 0 000Ch 0 Vacuum Head A6 Bit 0
1 Vacuum Head A1 Bit 1 1 Vacuum Head A6 Bit 1
2 Vacuum Head A1 Bit 2 2 Vacuum Head A6 Bit 2
3 Vacuum Head A1 Bit 3 3 Vacuum Head A6 Bit 3
4 Vacuum Head A1 Bit 4 4 Vacuum Head A6 Bit 4
5 Vacuum Head A1 Bit 5 5 Vacuum Head A6 Bit 5
6 Vacuum Head A1 Bit 6 6 Vacuum Head A6 Bit 6
7 Vacuum Head A1 Bit 7 7 Vacuum Head A6 Bit 7
0004h 0 Vacuum Head A2 Bit 0 000Ah 0 Vacuum Head A7 Bit 0
1 Vacuum Head A2 Bit 1 1 Vacuum Head A7 Bit 1
2 Vacuum Head A2 Bit 2 2 Vacuum Head A7 Bit 2
3 Vacuum Head A2 Bit 3 3 Vacuum Head A7 Bit 3
4 Vacuum Head A2 Bit 4 4 Vacuum Head A7 Bit 4
5 Vacuum Head A2 Bit 5 5 Vacuum Head A7 Bit 5
6 Vacuum Head A2 Bit 6 6 Vacuum Head A7 Bit 6
7 Vacuum Head A2 Bit 7 7 Vacuum Head A7 Bit 7
0005h 0 Vacuum Head A3 Bit 0 000Bh 0 Vacuum Head A8 Bit 0
1 Vacuum Head A3 Bit 1 1 Vacuum Head A8 Bit 1
2 Vacuum Head A3 Bit 2 2 Vacuum Head A8 Bit 2
3 Vacuum Head A3 Bit 3 3 Vacuum Head A8 Bit 3
4 Vacuum Head A3 Bit 4 4 Vacuum Head A8 Bit 4
5 Vacuum Head A3 Bit 5 5 Vacuum Head A8 Bit 5
6 Vacuum Head A3 Bit 6 6 Vacuum Head A8 Bit 6
7 Vacuum Head A3 Bit 7 7 Vacuum Head A8 Bit 7
