4 Electrical Section
4-15
■ Device 6
Monitor input of the front operation switches.
Address Bit No. Signal Name Address Bit No. Signal Name
000h 0 Device No. Bit 0 0002h 0 RESET (F)
1 Device No. Bit 1 1 START (F)
2 Device No. Bit 2 2 STOP (F)
3 Device No. Bit 3 3 CLEAR (F)
4 Device Added Information Bit 0 4 SAFETY (F)
5 Device Added Information Bit 1 5 READY (F)
6 Device Added Information Bit 2 6 ACTIVE (F)
7 Output Register Value Bit 0 7 DISPLAY (F)
0001h 0 Output Register Value Bit 1 0003h 0 DOCKING (F)
1 Output Register Value Bit 2 1 OPTION (F)
2 Output Register Value Bit 3 2
3 Output Register Value Bit 4 3
4 Input Register Value Bit 0 4
5 Input Register Value Bit 1 5
6 Input Register Value Bit 2 6
7 Input Register Value Bit 3 7
■ Device 8
Monitors input of the rear operation switches.
Address Bit No. Signal Name Address Bit No. Signal Name
000h 0 Device No. Bit 0 0002h 0 RESET (R)
1 Device No. Bit 1 1 START (R)
2 Device No. Bit 2 2 STOP (R)
3 Device No. Bit 3 3 CLEAR (R)
4 Device Added Information Bit 0 4 SAFETY (R)
5 Device Added Information Bit 1 5 READY (R)
6 Device Added Information Bit 2 6 ACTIVE (R)
7 Output Register Value Bit 0 7 DISPLAY (R)
0001h 0 Output Register Value Bit 1 0003h 0 DOCKING (R)
1 Output Register Value Bit 2 1 OPTION (R)
2 Output Register Value Bit 3 2
3 Output Register Value Bit 4 3
4 Input Register Value Bit 0 4
5 Input Register Value Bit 1 5
6 Input Register Value Bit 2 6
7 Input Register Value Bit 3 7
4 Electrical Section
4-16
■ Device 10
Monitor input of the rear operation switches.
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Device No. Bit 0 0006h 0 ANC A Close
1 Device No. Bit 1 1 ANC A Open
2 Device No. Bit 2 2
3 Device No. Bit 3 3
4 Device Added Information Bit 0 4
5 Device Added Information Bit 1 5
6 Device Added Information Bit 2 6
7 Output Register Value Bit 0 7
0001h 0 Output Register Value Bit 1 0008h 0 Board Stopper Up (option)
1 Output Register Value Bit 2 1 Board Stopper Down (option)
2 Output Register Value Bit 3 2 Entrance Shutter Close
3 Output Register Value Bit 4 3
4 Input Register Value Bit 0 4 Main Clamp Up
5 Input Register Value Bit 1 5 Main Clamp Down
6 Input Register Value Bit 2 6 Main Conveyor Arrival (option)
7 Input Register Value Bit 3 7 Entrance Sensor
0002h 0 Board Stopper Up 000Bh 0 Conveyor 1 Alarm
1 Board Stopper Down 1 Conveyor 2 Alarm
2 2 Conveyor 3 Alarm
3 AWC – Axis ORG 3
4 4
5 5
6 6
7 7
0003h 0 000Ch 0
1 1
2 2
3 Main Conveyor Arrival 3
4 Exit Sensor 4
5 5
6 6
7 7
4 Electrical Section
4-17
■ Device 12
Front Feeder Bank
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Device No. Bit 0 0004h 0
1 Device No. Bit 1 1
2 Device No. Bit 2 2
3 Device No. Bit 3 3 CTF (F) Shutter Open (R)
4 Device Added Information Bit 0 4 CTF (F) Shutter Close (R)
5 Device Added Information Bit 1 5 CTF (F) Shutter Open (L)
6 Device Added Information Bit 2 6 CTF (F) Shutter Close (L)
7 Output Register Value Bit 0 7 CTF (F) Stocker Pallet Interlock
0001h 0 Output Register Value Bit 1 0
1 Output Register Value Bit 2 1
2 Output Register Value Bit 3 2 CTF (F) Pallet Existence
3 Output Register Value Bit 4 3 CTF (F) Stocker Area
4 Input Register Value Bit 0 4 CTF(F) Cover Open
5 Input Register Value Bit 1 5 CTF (F) Setup Switch
6 Input Register Value Bit 2 6 CTF (F) Thermo Sensor
7 Input Register Value Bit 3 7 CTF (F) Hook Position 1
0002h 0 TI BOARD (F) ID 0 0006h 0 CTF (F) Hook Position 2
1 TI BOARD (F) ID 1 1 CTF (F) pallet Detect in Stocker
2 TI BOARD (F) ID 2 2 CTF (F) pallet Stopper (R)
3 TI BOARD (F) ID 3 3 CTF (F) Pallet Stopper (L)
4 TI BOARD (F) ID 4 4
5 TI BOARD (F) ID 5 5
6 TI BOARD (F) ID 6 6
7 TI BOARD (F) ID 7 7
0003h 0 TI BOARD (F) ID 8 0007h 0
1 TI BOARD (F) ID 9 1
2 TI BOARD (F) ID 10 2
3 TI BOARD (F) ID 11 3
4 TI BOARD (F) ID 12 4
5 TI BOARD (F) ID 13 5
6 TI BOARD (F) ID 14 6
7 TI BOARD (F) ID 15 7
