5 Materials
5-4
Replacement Parts
Head Manifold Section
Part Name Part Number Qty Remark
VALVE LE4-M71A1-A0X 4/8 Air Valve
FILTER (SZ65111) K46-M8527-C0X 4/8 Filter of Ejector
FILTER CAP LE4-M71A1-C0X 4/8 Filter Cap
O-RING LE4-M71A1-D0X 4/8 O-Ring of Ejector
ADAPTER LE4-M71A1-E0X 4/8 Filter Cap Assy.
MUFFLER LE4-M71A1-H0X 4/8 Silencer Element
MUFFLER ASSY. LE4-M71A1-F0X 4/8 Muffler Assy.
Note：”QTY” – necessary quantity for one unit
Nozzle Section
Part Name Part Number Qty Remark
O RING LC1-M77A5-90X 1
P005、P006、P013
P018、P019、P020
RUBB.PAD17 LG0-M77A0-00X 1 P017 Rubber PAD
RUBB.PAD18 LG0-M77A1-00X 1 P018 Rubber PAD
RUBB.PAD19 LG0-M77A2-00X 1 P019 Rubber PAD
RUBB.PAD20 LG0-M77A9-00X 1 P020 Rubber PAD
Note; “QTY” - necessary quantity for one nozzle of each type
Air Regulator Section
Part Name Part Number Qty Remark
MIST FILTER LE4-M11A1-00X 1 For mist separator
Note; “QTY” – necessary quantity for one machine
Grease
Part Name Part Number Qty Remark
GREASE,LR3 K48-M3856-000 1 LR3 Grease
GREASE,SILICON LG0-M89AB-00X 1 Silicone Grease
5 Materials
5-5
Electrical Section (Fuses used by the electrical boards)
PCB Name Reference Part Number Part Name
F１
LE4-M65W1-20X FUSE
XiO.Fi
F２
LE4-M65W1-00X FUSE
F1 LE4-M65W1-00X FUSE
F2,F4 LE4-M65W1-10X FUSE
XiO.Mi8 Rev.A
F3 LE4-M65W1-30X FUSE
F1,F9 LE4-M65W1-40X FUSE
F2 LE4-M65W1-50X FUSE
XiO.HiBLC
F3,F4,F5 LE4-M65W1-60X FUSE
XiO.Hi FU1,FU2 LE4-M65W1-50X FUSE
XiO.Ui FU1,FU2 LE4-M65W1-00X FUSE
XiO
F10～F12
F19～F39
LE4-M65W1-00X FUSE
Conveyor Belt
Type Part Name Part Number Qty Remark
LN-RN BELT,A LE4-M960H-10X 2 Standard
BELT,830 LE4-M953H-10X 2
LB-RN
BELT,1850 LE4-M953H-40X 2
Left : Buffer ⇔ Right : None
BELT,830 LE4-M953H-10X 2
LN-RB
BELT,1850 LE4-M953H-40X 2
Left : None ⇔ Right : Buffer
BELT,830 LE4-M953H-10X 2
LB-RB BELT,845 LE4-M953H-20X 2 Left : Buffer ⇔ Right : Buffer
BELT,1565 LE4-M953H-30X 2
LE-RN BELT,2550 LE4-M953H-60X 2 Left : Extension ⇔ Right : None
LN-RE BELT,2550 LE4-M953H-60X 2 Left : None ⇔ Right : Extension
LE-RE BELT,2950 LE4-M953H-70X 2 Left : Extension ⇔ Right : Extension
BELT,830 LE4-M953H-10X 2
LB-RE
BELT,2250 LE4-M953H-50X 2
Left : Buffer ⇔ Right : Extension
BELT,830 LE4-M953H-10X 2
LE-RB
BELT,2250 LE4-M953H-50X 2
Left : Extension ⇔ Right : Buffer
Note; The conveyor belt direction is the same in spit of the conveyor flow direction.
5 Materials
5-6
