1 Installation 1-1 1 Installation
4 Electrical Section........................................................................................4-1
Signal I/O............................................................................................................................4-2
Signal Input Monitor.................................................................................................4-2
DO Operation............................................................................................................4-5
Serial I/O...................................................................................................................4-6
DO Map ....................................................................................................................4-7
DI MAP ..................................................................................................................4-13
Xio BOARD Manual ........................................................................................................4-19
Serial I/O Operation Check LED............................................................................4-20
Operation Check LED ............................................................................................4-21
Control Board ...................................................................................................................4-24
Electrodes on Feeder / Feeder Bank .................................................................................4-25
Adjustment of Board Detection Sensors...........................................................................4-26
Entrance sensor / Exit sensor ..................................................................................4-26
PCB arrival sensor ..................................................................................................4-27
Motor Troubles .................................................................................................................4-30
Alarm Code List......................................................................................................4-30
Cautions about overall electrical items .............................................................................4-32
5 Materials ......................................................................................................5-1
Standard Accessories List ...................................................................................................5-2
Replacement Parts...............................................................................................................5-4
Air Circuit Diagram ............................................................................................................5-7
Electrical Block Diagram..................................................................................................5-10
1 Installation
1-1
1
Installation
1 Installation
1-2
Installation of Machine
Environmental Requirements
Install the machine at the place where the below conditions are met.
Do not do tasks, such as moving the machine or connecting the machine with the main switch ON to
prevent electric shock.
■ Ambient Temperature: Accuracy assurance 23 +/-2 degrees centigrade
Operation assurance +10 to +35 degrees centigrade
(The average over a period of 24 hours does not exceed 30 degrees C.)
■ Relative Humidity: 45 to 60 percent, non-condensing
■ Altitude : Altitude (elevation) below 1000m
■ Atmosphere: Dust and corrosive gas free
■ Floor: Floor must be flat and sturdy enough for freedom from vibration during
operation.
■ Power Requirements: 200 VAC +/- 10%, three phase, 50/60 Hz
* 200/208/220/240/380/400/416/440V VAC power transformer
Power consumption: 0.77KW
Capacity: 8.3KVA
Leakage current: 20mA or less
* Power and ground the machine independently of other machines which may be a
noise source, such as a compressor, welding machine, or reflow soldering machine
with magnetic contacts.
Warning
