1.15 Overview of the modules - PCB conveyor Software Version SR.501.xx 12/99 Issue US
48
t IIt
The conveyor belts are driven by DC motors. Each placement area has a lifting table for clamping
the PCBs. The width of the PCB conveyor can be adjusted either 1
– via the menu or
– using the line computer
1
1.15.2 Technical data - single conveyor
1
1.15.3 Technical data - dual conveyor
1
Fixed conveyor edge Right (standard), left (optional)
PCB format
50 mm x 50 mm to 368 mm x 460 mm
2" x 2" to 14.5 " x 18 "
PCB thickness 0.3 mm to 4.5 mm
Maximum PCB curvature
On top: 4.5 mm - PCB thickness
On bottom: 0.3 mm + PCB thickness
Clearance underneath PCB
Standard: 25 mm
Option: Up to 40 mm
PCB conveyor height
830 ± 15 mm (standard)
952,5 ± 15 mm (option) SMEMA
Type of interface
Siemens (standard)
SMEMA (option)
Clear guide edge of component 3 mm
PCB changeover time 2.5 s
Ink spot recognition Possible
Automatic width adjustment Possible
Fixed conveyor edge Right (standard), left (optional)
PCB format
50 mm x 50 mm to 368 mm x 216 mm
2" x 2" to 14.5" x 8.5"
PCB thickness 0.3 mm to 4.5 mm
Maximum PCB curvature
On top: 4.5 mm - PCB thickness
On bottom: 0.3 mm + PCB thickness
User Manual HS-50 1 Introduction
Software Version SR.501.xx 12/99 Issue US 1.15 Overview of the modules - PCB conveyor
49
t IIt
1
1
Clearance underneath PCB
Standard: 25 mm
Option: Up to 40 mm
PCB conveyor height
830 ± 15 mm (standard)
952,5 ± 15 mm (option) SMEMA
Type of interface
Siemens (standard)
SMEMA (option)
Clear guide edge of component 3 mm
PCB changeover time 2.5 s
Components on each conveyor Same or different
PCB width on each conveyor Same or different
Ink spot recognition Possible
Automatic width adjustment Possible
