7. Maintenance
0908-001
7. Maintenance
7.1 Precautions before Maintenance
This describes the check, cleaning, and adjustment for tape feeders operating in
good conditions.
A full and periodical maintenance of the tape feeder is recommended.
CAUTION
Only trained persons should perform maintenance,
both carefully and according to the specied
procedures.
OM-1606
7-2
7. Maintenance
7.2 Preparation for Maintenance
Preparation for Cleaning and Oiling
•
Rag (Extra Cloth)
Use a rag made of such material (cotton, etc.) that produces as less waste thread
as possible.
A clean rag must be used depending on a spot to be cleaned.
Notice
The remaining waste thread if any will cause the machine to break
down.
•
Alcohol
Do not use alcohol on unspeci ed locations.
•
Toothbrush
It is required for tape peeling section.
Use normal cotton swab or toothbrush on the market.
•
Air Gun
Do not use the air gun for any spots other than the specied ones.
If dirt and dust are dispersed, moving mechanisms, causing the tape feeder to
break down.
•
Vacuum Cleaner
If the suction hole of the vacuum cleaner is changed to a smaller one, some
spots can be cleaned more easily.
•
Cotton Applicator (SIGMA-G5 Main Machine Standard Accessory)
It is used for removing dirt stuck onto the sensor section.
•
Bamboo Probe (SIGMA-G5 Main Machine Standard Accessory)
It is used to remove dust stuck onto the sensor section.
•
Greasing Jig (SIGMA-G5 Main Machine Standard Accessory)
Grease is applied using this syringe type jig.
(When grease for one division on the gauge is injected, grease of 0.1 ml is
applied).
•
Greasing Jig Nozzle (SIGMA-G5 Main Machine Standard Accessory)
Grease is applied using this syringe type jig.
•
Grease
Use MOLYNOC GREASE AP1 (NIPPON OIL CORPORATION) or its
equivalent.
1005-002
OM-1606
7-3
7. Maintenance
MOLYNOC GREASE AP1 (NIPPON OIL CORPORATION) or its equivalent
Grease Names Makers
DAPHNE M-No.1 Idemitsu Kosan Co., Ltd
JOMO Lisonix Grease M No. 1 JAPAN ENERGY CORPORATION
COSMO MOLYBD GREASE No. 1 COSMO OIL LUBRICANTS
BEACON Q2 ESSO OIL
Gemico MD2 TonenGeneral Sekiyu K.K.
M5 GREASE 1 KYGNUS
TG1
