7.5.3 Wide Feeder Joint Detection Unit Sensor Section Cleaning
(GD-12162, GD-24322, GD-44562, GD-72002, GD-88002)
Procedure
(1) Remove the set screws and side cover on the joint detection unit to expose
the sensor section.
Set Screw
Sensor
After the removal
Side Cover
GD-12162, GD-24322, GD-44562 FG26
Set Screw
Set Screw
Sensor
After the removal
Side Cover
GD-72002, GD-88002 FG26-1
1011-002
OM-1606
7-21
7. Maintenance
(2) Clean the sensor section.
•
Debris Removal Operation
When any debris such as sticky substance, is stuck, rub it off using a bamboo
probe.
Bamboo Prove
FG27
•
Wiping Dirt Off
Insert a cotton applicator dipped in alcohol into the gap in the sensor section
to clean any dirt by rubbing. After cleaning the dirt by rubbing, rub it using a
dry cotton applicator.
FG28
(3) Check the sensor detection.
Using the same procedure for the 8 mm dual feeder, check the sensor
detection status.
Reference
Refer to "7.5.2.3 Sensor Detection Check" for details.
1011-002
OM-1606
7-22
7. Maintenance
7.6 Maintenance Component List
Listed below are the parts for which maintenance work is required in several
years. The list below is provided for your reference.
If the recommended years of the component has passed or the component is
damaged, replace it.
GT-28080, 28082 and GD-28080, 28082 Maintenance Component List_1
RY : Recommended Years
Component Name
PART No.
PART NAME Q'ty
RY
Yamaha Hitachi
Cover (LA)
KYD-MCN1P-00
0926B00A
COVER(LA)
1 1
Cover (LB)
KYM-M864M-00
211AD442
COVER(LB)
1 1
Cover (RA)
KYD-MCN1R-00
0926B00B
COVER(RA)
1 1
Cover (RB)
KYM-M864N-00
211AD444
COVER(RB)
1 1
Cover (KIBAN)
KYD-MCN1S-00
0926B015
COVER
1 1
Conductive Lever
KYD-MC11Y-00
216S3122
LEVER(GRIP)
1 -
Conductive Grip
KYD-MC109-00
0926B00H
GRIP
1 -
Conductive Cover
KYD-MC11W-00
211AB843
COVER(GRIP)
1 -
Front End Guide
KYD-MC13H-00
212A2190
GUIDE
1 1
Cover Tape Outlet Cover
KYD-MCN3F-00
211AD370
COVER
2 1
Cutter
KYD-MC13X-00
226J1909
MECH-P_CUTTER
1 2
Suppressor Lock Spring
KYD-MCN41-00
222M1491
SPRING_COMP
1 2
Feed Worm Gear ASSY (L)
KYF-M8646-00
023E0045
ASSY_GEAR
1 3
Feed Worm Gear ASSY (R)
KYF-M8647-00
023E0046
ASSY_GEAR
1 3
Feed Worm Wheel ASSY
KYD-MCN0W-00
09261106
ASSY_GEAR
2 3
Sprocket ASSY (L)
KYH-M8620-00
09261102
ASSY,SPROCKET
1 3
Sprocket ASSY (R)
KYM-M861C-00
023S0114
ASSY_SPROCKET
1 3
Timing Belt
KYD-MC13V-00
223L0270
BELT_TIMING
2 4
Take-up Base ASSY (L)
KYM-M861M-00
09261204
ASSY_BASE(L)
1 3
Take-up Gear
(Flat End Wheel 2)
KYM-M8610-00
223E0516
GEAR
1 4
Take-up Gear
(Flat End Wheel 2)
KYM-M8610-00
223E0516
GEAR
1 4
Take-up Gear
(Worm Wheel)
KYK-M860C-00
223E0458
GEAR
1 3
Take-up Gear
(Worm Wheel)
KYK-M860C-00
223E0458
GEAR
1 3
Roll-in Preventive Plate
(Down)
KYD-MC11X-00
211AC677
COVER(MAKI-2)
1 3
Roll-in Preventive Plate
(Down)
KYD-MC11X-00
211AC677
COVER(MAKI-2)
1 3
Take-up Base ASSY (R)
KYM-M861N-00
09261205
ASSY_BASE(R)
1 3
TG5
Note
The numbers entitled "Recommended Years" indicate the referential values.
