OM-1606 8-6 8. Specications of T ape Feeders 8.2 Specications of 12/16 mm T ape Feeder Model T ape Width × Feed Pitch (mm) T ypes of T ape Standard Set Reel Outer Diameter × Width (mm) Chute Height (mm) Referential Com…
OM-1606
8-5
8. Specications of Tape Feeders
(f) Use a taping on condition that the component itself or its electrical contact
is not protruded from the upper surface of tape.
Embossed Taping
"Embossed depth (T
3
) > Component thickness"
Cover Tape
Component
T3
FH7
(g) Shown in column "t" is the gap between the component pick-up and chute
surfaces.
As the gap can be adjusted by the stroke control, set the pick-up level data
in the component library data.
If dimension "t" is big, components may not stay still or may be tilted.
Be sure to adjust the dimension for the appropriate one in the range of
values specied in the table.
(h) The shape of component pick-up surface should be wide and smooth
enough to be picked up by vacuum nozzles.
(i) Cover tapes sometimes become thicker than expected due to leafy and
uffy leftovers produced through the production process.
However, the overall thickness should not exceed the value described as
"T
2
" in the table.
0908-001
OM-1606
8-6
8. Specications of Tape Feeders
8.2 Specications of 12/16 mm Tape Feeder
Model
Tape Width
×
Feed Pitch
(mm)
Types of
Tape
Standard
Set
Reel Outer
Diameter
×
Width (mm)
Chute
Height
(mm)
Referential
Components
Remarks
GT-12162
GD-12162
12 × 4 Embossed
L : f 382 × 18.4
S : f 178 × 18.4
104.0
• Barcode Label Color :
White
12 × 8 Embossed
12 × 12 Embossed
16 × 4 Embossed
L : f 382 × 22.4
16 × 8 Embossed
16 × 12 Embossed
16 × 16 Embossed
TH4
Note
If a 16 mm width tape is to be used, then a tape guide and support suppressor
detachments are required.
Reference
Refer to "2.5 Tape Guide and Support Suppressor" for the tape guide and support
suppressor removal procedures.
1005-002
OM-1606
8-7
8. Specications of Tape Feeders
8.2.1 Referential Dimension for Taping
Embossed Carrier Type Taping
Cover Tape
Taped Component
(Sprocket Hole)
Direction of Unreeling
Cover Tape
Sprocket Hole
Reel
Embossed Carrier Tape
Embossed Hole
Component
Compartment
FH8 FH9
Dimensions for Taping (mm)
Tape Width
×
Feed Pitch
(mm)
A
0
B
0
W F E P
1
P
2
P
0
D
0
T T
2
K D
1
C t
12 4
More than
1.6 to 3.4
or less
8.3
or less
12.0
0.3
5.5
0.05
1.75
0.1
4.0
0.1
2.0
0.05
4.0
0.1
1.5
0.1
0
0.35
or less
12.1
or less
12.0
or less
0.5
or more
8.4
or less
0.2
to
- T
(g)
12 8
More than
3.4 to 7.4
or less
8.3
or less
12.0
0.3
5.5
0.05
1.75
0.1
8.0
0.1
2.0
0.05
4.0
0.1
1.5
0.1
0
0.35
or less
12.1
or less
12.0
or less
1.5
or more
8.4
or less
0.2
to
- T
(g)
12 12
More than
7.4 to 10.8
or less
8.3
or less
12.0
0.3
5.5
0.05
1.75
0.1
12.0
0.1
2.0
0.05
4.0
0.1
1.5
0.1
0
0.35
or less
12.1
or less
12.0
or less
1.5
or more
8.4
or less
0.2
to
- T
(g)
16 4
More than
1.6 to 3.4
or less
11.9
or less
16.0
0.3
7.5
0.1
1.75
0.1
4.0
0.1
2.0
0.1
4.0
0.1
1.5
0.1
0
More than
0.3 to 0.6
or less
12.1
or less
12.0
or less
1.5
or more
12.3
or less
1.0
to
- T
(g)
16 8
More than
3.4 to 7.4
or less
11.9
or less
16.0
0.3
7.5
0.1
1.75
0.1
8.0
0.1
2.0
0.1
4.0
0.1
1.5
0.1
0
More than
0.3 to 0.6
or less
12.1
or less
12.0
or less
1.5
or more
12.3
or less
1.0
to
- T
(g)
16 12
More than
7.4 to 10.8
or less
11.9
or less
16.0
0.3
7.5
0.1
1.75
0.1
12.0
0.1
2.0
0.1
4.0
0.1
1.5
0.1
0
More than
0.3 to 0.6
or less
12.1
or less
12.0
or less
1.5
or more
12.3
or less
1.0
to
- T
(g)
16 16
More than
10.8 to 14.6
or less
11.9
or less
16.0
0.3
7.5
0.1
1.75
0.1
16.0
0.1
2.0
0.1
4.0
0.1
1.5
0.1
0
More than
0.3 to 0.6
or less
12.1
or less
12.0
or less
1.5
or more
12.3
or less
1.0
to
- T
(g)
TH5
Note
(a) A
0
×
B
0
stands for the rectangle hole size on the tape.
The clearance between a rectangle hole and a component affects the pick-
up rate.
Use the taping component with appropriate clearance specications.
(b) The above specications do not imply any guarantee of pick-up rate, etc.
The pick-up rate varies depending on how the main machine is adjusted
and the combination of the main machine and the tape feeders.
(c) Make a hole (D
1
) in the cavity if necessary.
(d) 10 pitches cumulative tolerance P
0
should be ± 0.2 mm.
(e) The cover tape should run smoothly along the sprocket holes.
The edges of the cover tape should be aligned with the carrier tape (taping).
The thickness of the cover tape should be 0.07 mm or less (including waste
paper).
