OM-1606 1 1-5 1 1. T roubleshooting 1005-002 Notice Remedy : Remove any chip component or foreign substance such as debris attached onto the sprocket and completely clean the sprocket. Cause : Chip component or foreign s…
OM-1606
11-4
11. Troubleshooting
1005-002
11.3 Tape Feed not correctly performed
Remedy
: Remove any chip component or foreign substance such as debris attached onto the
suppressor and completely clean the suppressor.
If the taping component is mounted with any foreign substance attached, the suppresser
might be deformed or a pick-up error occur.
Therefore, clean it.
Cause : Chip component or foreign substances including debris have been
attached inside the suppressor and the suppressor does not securely
hold the tape.
Notice
Chip component or foreign
substances including debris
Remedy
: Engage the carrier tape sprocket hole with the sprocket teeth.
Cause : Carrier Tape Sprocket Hole not engaged with the sprocket teeth.
Remedy
: Lock the suppressor with the front hook.
Cause : Front hook has not locked properly and the suppressor does not hold
the tape securely.
OM-1606
11-5
11. Troubleshooting
1005-002
Notice
Remedy
: Remove any chip component or foreign substance such as debris attached onto the
sprocket and completely clean the sprocket.
Cause : Chip component or foreign substances including debris have been
attached onto the sprocket and the sprocket does not rotate.
Chip component or foreign
substances including debris
Remedy
: Remove any chip component or foreign substance such as debris attached on the chute
and completely clean the surface of the chute.
If the taping component is mounted with any foreign substance attached, the suppressor
might be deformed or a pick-up error occur.
Therefore, clean it.
Cause : Chip component or foreign substances including debris have been
attached onto the chute and the suppressor does not securely hold the
tape.
Chip component or foreign
substance such as debris
OM-1606
11-6
11. Troubleshooting
0908-001
•
Only for tapes with 12 mm width in GT-12162 or GD-12162, 24 mm width in GT-24322 or
GD-24322, and 44 mm width in GT-44562 or GD-44562
Remedy
: Remove any chip component or foreign substance such as debris attached onto the
tape guide attachment surface and completely clean the tape guide attachment surface.
Cause : Chip component or foreign substances including debris have been
attached onto the tape guide attachment surface.
Chip component or foreign
substance such as debris
•
Only for tapes with 12 mm width in GT-12162 or GD-12162, 24 mm width in GT-24322 or
GD-24322, and 44 mm width in GT-44562 or GD-44562
Remedy
: Attach the support suppressor.
Cause : The support suppressor not attached
For tape of 12 mm width For tape of 24 mm width For tape of 44 mm width
