Section5 Electrical Circuit Diagram 0305-001- (M805WBB--0009) 5-19 Tg0861-PM-MD SDS IN 2 Option Reserved Reserved Reserved Reserved P .C.B. Clamp Detection Fixed Side (Option) Extended ER Conveyor Exitence Detection (Opt…
Section5 Electrical Circuit Diagram
SDS IN 1
0305-001- (M805WBB--0008) 5-18 Tg0861-PM-MD
L Conveyor P.C.B.
Detection L
L Conveyor P.C.B.
Detection C
L Conveyor P.C.B.
Detection R
P Conveyor P.C.B.
Detection L
P.C.B. Stopper L Upper
Limit
P.C.B. Stopper L Lower
Limit
P.C.B. Support Pin Detection
(Front Reference)
Traverse Axis
Circuit Breaker OFF
Reserved
Reserved
Reserved
Reserved
Reserved
Extended EL Conveyor
Existence Detection
(Option)
Extended EL Conveyor
P.C.B. Detection L
(Option)
Extended EL Conveyor
P.C.B. Detection R
(Option)
To the extended EL
conveyor (Option)
BL Block
N Block
Section5 Electrical Circuit Diagram
0305-001- (M805WBB--0009) 5-19 Tg0861-PM-MD
SDS IN 2
Option
Reserved
Reserved
Reserved
Reserved
P.C.B. Clamp Detection
Fixed Side (Option)
Extended ER Conveyor
Exitence Detection
(Option)
Extended ER Conveyor
P.C.B. Detection R
(Option)
Extended ER Conveyor
P.C.B. Detection L
(Option)
N Block (option)
To the Extended ER
conveyor (option)
R Conveyor
P.C.B. Detection R
R Conveyor
P.C.B. Detection C
R Conveyor
P.C.B. Detection L
P Conveyor
P.C.B. Detection R
P.C.B. Stopper R Upper
Limit
P.C.B. Stopper R Lower
Limit
P.C.B. Support pin
Detection
(Rear Reference)
P.C.B. Clamp Detection
(Option)
N Block
Section5 Electrical Circuit Diagram
0305-001- (M805WBB--0010) 5-20 Tg0861-PM-MD
SDS IN 3
B (A) Block
F (A1) Block
To Component Discharge
Conveyor A (Option)
*To the right
side of the
figure
[MANUAL] Switch A
(Option)
To Component Discharge
Conveyor A (Option)
*From the left side
of the figure
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Component Discharge
Conveyor A
Type Code 1 (Option)
Component Discharge
Conveyor A
Type Code 2 (Option)
Component Discharge Box A
Full Detection
Component Discharge Conveyor A
Full Detection (Option)
Component Discharge Conveyor A
Discharge Position Detection
(Option)
[MANUAL] Switch A
(Option)
Nozzle Stocker A1
Open Check
Nozzle Stocker A1
Close Check
Nozzle Stocker A2 Open
Check (option)
Nozzle Stocker A2 Open
Open (option)
