ALL PURPOSE CLAMPING (APC) PNEUMATIC SCHEMATIC 1.20 All Purpose Clamping (APC) Manual Chapter Issue 1 Nov 16 PNEUMA TIC SCHEMA TIC Figure 1-10 APC Pneumatic Schematic V alve 1 Mid Plate Up V alve 2 Mid Plate Down V alve …
ALL PURPOSE CLAMPING (APC)
ELECTRICAL SCHEMATICS
Chapter Issue 1 Nov 16 All Purpose Clamping (APC) Manual 1.19
Figure 1-9 Modular Transport Rails Schematic
Machine PC
Motherboard
Machine Control Enclosure
NextMove
Interface Card
X4
NextMove ES
(I/O Node 1)
X5
USB
Board at Left
Sensor (8SE8)
8PL10
8PL04
Sig
+12V
0V
8PL22
M36PL18
Moving Rail
Home (8SE6)
8PL26
M36PL19
+12V
0V
Sig
Rail Lift Right
(8SE4)
+12V
Sig
0V
(L)
8SK23 8PL29
Rear Belt
Drive (8M04)
Dual Speed
Motor
Dual Speed
Motor
Controller
8SK21 8PL29
Front Belt
Drive (8M03)
Dual Speed
Motor
Dual Speed
Motor
Controller
8PL15
Rail Lift Left
(8SE5)
+12V
Sig
0V
8PL12
Board at Right
Sensor (8SE7)
8PL03
Sig
+12V
0V
ALL PURPOSE CLAMPING (APC)
PNEUMATIC SCHEMATIC
1.20 All Purpose Clamping (APC) Manual Chapter Issue 1 Nov 16
PNEUMATIC SCHEMATIC
Figure 1-10 APC Pneumatic Schematic
Valve 1
Mid Plate Up
Valve 2
Mid Plate Down
Valve 3
Over Top Clamp
Extend / Retract
Valve 6
Z Clamps
Balance
Valve
Software Controlled
Air Regulator Unit
Mid Plate Cylinder
Overtop Cylinder
Z Clamps
Mid Plate Cylinder
Overtop Cylinder
Z Clamps
Rear Clamp
Front Clamp
ALL PURPOSE CLAMPING (APC)
ADJUSTMENTS AND SETTINGS
Chapter Issue 1 Nov 16 All Purpose Clamping (APC) Manual 1.21
ADJUSTMENTS AND SETTINGS
Vision Height
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
NOTE
Ensure the board file used has the correct board thickness value. Check rail /
camera X motor bracket clearance. Remember that the vision height may be
higher if a thinner board is used.
1. Select Unload Screen.
2. Open the front printhead cover.
3. Remove the screen from the machine.
4. Place the board on the rails and slide to a central position.
5. Refit the screen.
6. Close the front printhead cover.
7. Press the System button.
8. Select Load Screen.
9. Select Maintenance.
10. Select Diagnostics.
11. Use Next or Previous to highlight Rail System.
12. Select Select Module.
13. Use Next or Previous to highlight Toggle Board Clamp.
14. Select Run Diagnost.
15. Select Exit.
16. Use Next or Previous to highlight Rising Table.
17. Select Select Module.
18. Use Next or Previous to highlight Raise Table To Vision Height.
19. Select Run Diagnost.
20. Remove the left hand safety cover.
21. Using a suitable metric rule, measure the distance between the bottom of
the screen to the top of the board.
If the dimension is 79.5mm, go to Step 28.
22. Use Next or Previous to highlight Drive Table Using Jog Buttons.
23. Select Run Diagnost.
24. Using jog buttons drive the rising table to achieve a vision height of 79.5mm.
NOTE
The right jog button drives the rising table up, the left jog button drives the
rising table down. The rising table must not be jogged up higher than the
specified dimension, camera damage may occur.
